Rear Panel Components

No.
1
2
3
4
Related Information
"Cabling Requirements" on page 55
■
"Server Overview" on page 12
■
"Rear Panel Components" on page 14
■
Rear Panel Components
Note -
connect the power cords until all data cables have been connected.
No.
1
2
3
4
5
6
14 SPARC T5-4 Server Installation Guide • July 2015
Description
Power button
VGA port
SER MGT port
USB 3.0 ports
You must follow the proper sequence when connecting cables to the server. Do not
Description
Power supply unit AC inputs
NET MGT RJ-45 network port
SER MGT RJ-45 serial port
Network 10GbE ports: NET0—NET3
USB 3.0 ports
VGA port
Links
"NET MGT Port" on page 59
"SER MGT Ports" on page 58
"Gigabit Ethernet Ports" on page 60
"USB Ports" on page 57
"VGA Port" on page 60
