Rack Compatibility

Rack Compatibility

The rackmount kit is compatible with equipment racks that meet the following standards.
Item
Rack types when used with the CMA comb,
part number 7069793
Rack type when used with the multi-piece
CMA, part number 7041990
Structure
Rack horizontal opening and unit vertical pitch
Rack rail mounting hole sizes
Distance between front and rear mounting
planes
Clearance depth in front of front mounting
plane
Clearance depth behind front mounting plane
Clearance width between front and rear
mounting planes
Server dimensions
Related Information
"Physical Specifications" on page 17
■
"Tools Needed for Installation" on page 27
■
"Determine Correct Rackmount Hardware" on page 36
■
"Rackmount Kit (Part number 7069640)" on page 32
■
"Rackmount Kit (Part number 350-1662-02)" on page 34
■
30 SPARC T5-4 Server Installation Guide • July 2015
Requirement
1000-mm and 1200-mm racks
1200-mm rack only.
Four-post rack (mounting at both front and rear). Two-post racks
are not compatible.
Conforms to ANSI/EIA 310-D-1992 or IEC 60927 standards.
9.5-mm square holes, M6 round mounting holes and 10-32
mounting holes are supported. All other sizes, including 7.2-mm or
M5 mounting holes, are not supported.
Minimum: 24 in. (240 mm)
Maximum: 36 in. (915 m)
Distance to front rack door is at least 1 in. (25.4 mm).
Distance to rear rack door is at least 34.6 in. (878.8 mm) with the
cable management arm, or 31.5 in. (800 mm) without the cable
management arm.
Distance between structural supports and cable troughs is at least
18.9 in. (480 mm).
Depth: 31.5in. (800 mm)
Width: 17.5 in. (445 mm)
Height: 8.5 in. (215 mm)
