Rear Panel Components (Installation) - Oracle SPARC S7-2 Installation Manual

No. Description
4 Service Action Required LED
(amber)
5 Power/OK LED (green)
6 Power button
7 SP OK/Fault LED (green or
amber)
8 Fan Service Action Required LED
(amber)
9 PS Service Action Required LED
(amber)
Related Information
"Server Overview" on page 11
■
"Rear Panel Components (Installation)" on page 13
■

Rear Panel Components (Installation)

Note - You must follow the proper sequence when connecting cables to the server. Do not
connect the power cords until all data cables have been connected.
No.
1
2
No.
13
14
15
16
17
18
Description
Power supply 0 Fault LED
Power supply 0 OK LED

Rear Panel Components (Installation)

Description
Drive 2 (HDD/SDD) or NVMe 0
Drive 3 (HDD/SDD) or NVMe 1
Drive 4 (HDD/SDD) or NVMe 2
Drive 5 (HDD/SDD) or NVMe 3
Drive 6 (HDD/SDD)
Drive 7 (HDD/SDD)
No.
8
9
Understanding the Server
Description
NET 0 100/1000/10000 port
NET 1 100/1000/10000 port
13
