Connect a Terminal or Emulator to the SER MGT Port
Caution -
to a serial terminal or a terminal emulator (PC or workstation). The server goes into Standby
mode and the Oracle ILOM SP initializes as soon as a power cable connects a power supply
to an external power source. System messages might be lost after 60 seconds if a terminal or
terminal emulator is not connected to the SER MGT port before power is applied.
Note -
since it will be a nonredundant condition. Do not be concerned with this fault in this situation.
Route the power cords from the AC power source to the rear of the server.
Do not attach the power cords to the power supplies at this time.
Related Information
"Rear Panel Components" on page 14
■
"Powering On the Server for the First Time"
■
Connect a Terminal or Emulator to the SER MGT Port
Prior to powering on the server for the first time, make a serial connection to the SP from a
terminal or terminal emulator. After making this serial connection, you will be able to view the
system messages when you connect the power cords.
Confirm that you have completed the following tasks:
1.
a.
Completed the preparation for installation.
See
b.
Completed the installation of the server in a rack.
See
c.
Connected the necessary cables.
See
Connect a terminal or a terminal emulator (PC or workstation) to the server SER
2.
MGT port.
Configure a terminal or terminal emulator with these settings:
3.
■
9600 baud
68
SPARC T5-4 Server Installation Guide • July 2015
Do not attach power cables to the power supplies until you have connected the server
Oracle ILOM will signal a fault if both power supplies are not cabled at the same time,
"Preparing for
Installation".
"Installing the
Server".
"Connecting the Server Cables"
