EX3200 Switch Hardware Guide
Table 52: QSFP+ Network Port Connector Pinout Information (continued)
Pin
36
37
38
Related
Documentation

RJ-45 to DB-9 Serial Port Adapter Pinout Information

Related
Documentation

Uplink Modules Connector Pinout Information for EX3200 Switches

126
Signal
TX1p
TX1n
GND
Installing a Transceiver on page 201
The console port is an RS-232 serial interface that uses an RJ-45 connector to connect
to a management device such as a PC or a laptop. If your laptop or PC does not have a
DB-9 male connector pin and you want to connect your laptop or PC to the device, use
a combination of the RJ-45 to DB-9 female adapter along with a USB to DB-9 male
adapter.
Table 53 on page 126 provides the pinout information for the RJ-45 to DB-9 serial port
adapter.

Table 53: RJ-45 to DB-9 Serial Port Adapter Pinout Information

RJ-45 Pin Signal
1 RTS
2 DTR
3 TXD
4 GND
6 RXD
7 DSR
8 CTS
Connecting a Device to a Management Console by Using an RJ-45 Connector on page 168
EX3200 switches have a field-replaceable unit (FRU) uplink module on the front panel.
Table 54 on page 127 provides the uplink modules connector pinout information.
DB-9 Pin Signal
8 CTS
6 DSR
2 RXD
5 GND
3 TXD
4 DTR
7 RTS
