Graphical Chassis Viewer

Table 15: Details of a Virtual Chassis Member Switch

Details
Model number of the member switch
Assigned ID that applies to the entire Virtual Chassis
configuration
Role of the member switch
Status of the member switch

Table 16: Status of a Member Switch in a Virtual Chassis

If the member switch is
Present
36
File System Usage on page 42
Chassis Viewer on page 42
The Dashboard panel displays a graphical view of the switch chassis. In a Virtual Chassis,
it displays a graphical view of each member switch.
In a Virtual Chassis, the default values are shown on the Dashboard panel when no chassis
image is clicked. The panel displays the value for a switch if you click its image.
NOTE: If the member switch is disconnected from the Virtual Chassis, inactive,
or not provisioned, you cannot expand the image of the member switch.
Table 15 on page 36 lists the details that are displayed on each member switch.
The status of the member switch is displayed on the image of the switch. If the image of
the member switch appears dimmed, it means that the switch is disconnected from the
virtual Chassis, is inactive, or is not provisioned in the Virtual Chassis. If the image of the
member switch does not appear dimmed, it means that the switch is present and is
active.
Table 16 on page 36 describes the possible statuses of a member switch.
It appears as
Prsnt
Example
EX3300
ID 2
NOTE: If the member switch is not provisioned, the serial number
of the switch is displayed instead of its ID.
Master
Possible roles are: ,
Master Backup
Prsnt
Possible statuses are: ,
Prsnt NotPrsnt
It means the member switch
Has established physical and logical connections with Virtual
Chassis member switches.
, or
Linecard
, , or
Inactive Unprvsnd
