Mounting an EX3200 Switch

Related
Documentation
142
Follow instructions for connecting power as appropriate for your site:
4.
Connecting AC Power to an EX3200 Switch on page 161
Connecting DC Power to an EX3200 Switch on page 163
Perform initial configuration of the switch by following instructions in
5.
and Configuring an EX Series Switch (CLI Procedure)" on page 175
Configuring an EX Series Switch (J-Web Procedure)" on page
Set the switch's management options by following the appropriate instructions:
6.
Connecting a Device to a Network for Out-of-Band Management on page 167
Connecting a Device to a Management Console by Using an RJ-45 Connector on
page 168
Rack Requirements on page 64
Cabinet Requirements on page 65
Clearance Requirements for Airflow and Hardware Maintenance for EX3200 Switches
on page 66
You can mount the switch:
On two posts in a 19-in. rack or cabinet by using the mounting brackets provided with
the switch.
On four posts in a 19-in. rack or cabinet by using the separately orderable four-post
rack-mount kit.
In a position recessed 2 in. from the front of a 19-in. rack or cabinet by using the
2-in.-recess front brackets in the separately orderable four-post rack-mount kit. You
can mount the switch in this recessed position on two-post or four-post racks and
cabinets.
On a desk or other level surface by using rubber feet. The switch is shipped with four
rubber feet to be used to stabilize the chassis on a desk or other level surface.
On a wall by using the separately orderable wall-mount kit.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm.) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
See the Related Documentation for detailed descriptions of the various rack or cabinet
mounting options.
Mounting an EX3200 Switch on Two Posts in a Rack or Cabinet on page 144
Mounting an EX3200 Switch on Four Posts in a Rack or Cabinet on page 146
Mounting an EX3200 Switch in a Recessed Position in a Rack or Cabinet on page 150
"Connecting
or "Connecting and
178.
