RJ-45 Management Port Connector Pinout Information

Table 48: RJ-45 Management Port Connector Pinout Information

Pin Signal
1 TRP1+
2 TRP1-
3 TRP2+
4 TRP3+
5 TRP3-
6 TRP2-
7 TRP4+
8 TRP4-
