High-performance businesses demand high-
performance networking solutions. The Juniper
Networks EX 3200 series fixed-configuration
Ethernet switches offer a compact, high-
performance solution for supporting today's
converged network access deployments.
Juniper Networks EX 3200
Series Fixed-Configuration
Ethernet Switches
Product Description
The EX 3200 series fixed-configuration switches from Juniper Networks offer a high-
performance standalone solution for access-layer deployments in branch and remote
offices as well as campus networks.
Featuring complete Layer 2 and Layer 3 switching capabilities, the EX 3200 series
switches satisfy the wiring closet connectivity requirements of today's high-
performance businesses. Four platform configurations are available offering 24 and 48
10/100/1000BASE-T ports with either full or partial Power over Ethernet (PoE). The base
24- and 48-port EX 3200 series switches deliver a full 15.4 watts of Class 3 PoE on the
first eight ports for supporting IP-enabled devices such as telephones, video cameras
and wireless LAN (WLAN) access points in converged networks. The EX 3200 series
switches with full PoE deliver 15.4 watts on all 24 or 48 ports to support high-density IP
telephony and other converged network environments.
The EX 3200 series Ethernet switches also support optional four-port Gigabit Ethernet
(GbE) and two-port 10GbE uplink modules with pluggable optics to provide high-
speed connectivity to aggregation-layer switches or other upstream devices. A field-
replaceable power supply and fan tray minimize mean time to repair (MTTR) for the EX
3200 series switches, ensuring maximum availability. When deployed with an optional
external redundant power supply unit, the EX 3200 series switch's power supply
becomes hot-swappable.
The EX 3200 series switches offer an integrated Route Engine (RE) that runs the
same modular JUNOS
™
software as Juniper router products to ensure the consistent
implementation and operation of each control plane feature across an entire Juniper
infrastructure.
Each EX 3200 series switch includes an integrated application-specific integrated
circuit (ASIC)-based packet forwarding engine, the EX-PFE, to consistently deliver
wire-rate forwarding even with all control-plane features enabled. Based on existing
field-proven Juniper technology, the EX-PFE and RE bring the same level of carrier-class
performance and reliability to the EX 3200 series switches that Juniper routers bring to
the world's largest service provider networks.
Standalone solution offering configuration flexibility and field serviceability
• Optional GbE and 10GbE uplinks reduce capital costs for remote office
deployments
• Field replaceable power supply and fan tray lower MTTR and increase
serviceability
• Single release train for JUNOS software ensures consistent control plane
feature implementation
• Modular JUNOS software prevents a switch reboot if a single protocol
feature fails
• LCD panel provides a simplified interface for device bring-up, recovery and
health checking without requiring a console
• Single management interface
• Up to 37 percent lower power consumption than comparable switches
Datasheet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX 3200 and is the answer not in the manual?

Questions and answers

Related Manuals for Juniper EX 3200

Summary of Contents for Juniper EX 3200

  • Page 1 10/100/1000BASE-T ports with either full or partial Power over Ethernet (PoE). The base performance networking solutions. The Juniper 24- and 48-port EX 3200 series switches deliver a full 15.4 watts of Class 3 PoE on the first eight ports for supporting IP-enabled devices such as telephones, video cameras Networks EX 3200 series fixed-configuration and wireless LAN (WLAN) access points in converged networks.

  • Page 2: Features And Benefits

    • Hot-swappable fan tray: The EX 3200 series fixed-configuration switches include a hot-swappable, field-replaceable fan tray, The EX 3200 series switches occupy a single rack unit and deliver reducing MTTR. a compact solution for crowded wiring closets and access locations •...

  • Page 3: Product Options

    IP infrastructure. The base system, which offers eight PoE ports, lowers the cost and complexity of Figure 3: The EX 3200 series switches work with the Juniper UAC solution designing the access layer by supporting a small number of WLAN to enforce access control down to the individual port level.
  • Page 4 EX 3200 Series Fixed-Configuration Ethernet Switch Specifications Physical Specifications Physical Layer • 24-port switches: • Physical port redundancy: Redundant trunk group (RTG) – 24 10/100/1000BASE-T ports: 8 PoE @ 15.4 W; 320 W PSU • Time Domain Reflectometry (TDR) for detecting cable breaks and shorts – 24 10/100/1000BASE-T ports: 24 PoE @ 15.4 W; 600 W PSU • Auto MDI/MDIX support • 48-port switches: • Port speed downshift/setting max advertised speed on – 48 10/100/1000BASE-T ports: 8 PoE @ 15.4 W; 320 W PSU 10/100/1000BASE-T ports – 48 10/100/1000BASE-T ports: 48 PoE @ 15.4 W; 930 W PSU Packet Switching Capacities • Uplink module options: –...
  • Page 5 Security • LAG load-sharing algorithm – Bridged Multicast Traffic: – IP: S/D MAC, S/D IP • MAC limiting – TCP/UDP: S/D MAC, S/D IP, S/D Port • Allowed MAC addresses – configurable per port – Non-IP: S/D MAC • Dynamic ARP Inspection (DAI) • LAG-sharing algorithm – Routed Multicast Traffic: • Local proxy ARP – IP: S/D MAC, S/D IP • Static ARP support – TCP/UDP: S/D MAC, S/D IP, S/D Port • DHCP snooping – Non-IP: S/D MAC Access Control Lists (ACLs) (JUNOS firewall filters) • Tagged ports support in LAG group • Port-based ACL (PACL) – Ingress Quality of Sevice (QoS) • VLAN-based ACL (VACL) – Ingress and Egress • Layer 2 QoS...

  • Page 6: Troubleshooting

    320 W AC PSU Safety and Compliance Advanced Feature License for EX 3200-24T, EX-AFL-24* EX 3200-24P Safety Certifications EX-AFL-48* Advanced Feature License for EX 3200-48T and • UL-UL60950-1(First Edition) EX 3200-48P switches • C-UL to CAN/CSA 22.2 No.60950-1(First Edition) Uplink Modules • TUV/GS to EN 60950-1, Amendment A1-A4, A11 2-port 10GbE XFP Uplink Module EX-UM-2XFP • CB-IEC60950-1, all country deviations...

  • Page 7: About Juniper Networks

    About Juniper Networks Juniper Networks, Inc. is the leader in high-performance networking. Juniper offers a high-performance network infrastructure that creates a responsive and trusted environment for accelerating the deployment of services and applications over a single network. This fuels high-performance businesses. Additional information can be found at www.juniper.net.
  • Page 8 Networks logo, NetScreen, and ScreenOS are registered trademarks of Juniper Networks, Inc. To purchase Juniper Networks solutions, please in the United States and other countries. JUNOS and JUNOSe are trademarks of Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service contact your Juniper Networks sales representative marks are the property of their respective owners.
