CHAPTER 7

Power Specifications and Requirements

Power Specifications for EX3200 Switches

Table 36: AC Power Supply Electrical Specifications

Item
AC input voltage
AC input line frequency
AC system current rating

Table 37: DC Power Supply Electrical Specifications

Item
DC input voltage
DC input current
Power supply output
Copyright © 2016, Juniper Networks, Inc.
Power Specifications for EX3200 Switches on page 69
AC Power Cord Specifications for EX3200 Switches on page 70
Calculating the EX Series Switch Fiber-Optic Cable Power Budget on page 72
Calculating the EX Series Switch Fiber-Optic Cable Power Margin on page 72
This topic describes power specifications for power supplies for EX3200 switches.
Table 36 on page 69 provides the AC power supply electrical specifications for EX3200

switches.

Table 37 on page 69 provides the DC power supply electrical specifications for EX3200
switches.
Specification
100 through 240 VAC
50 through 60 Hz
4 A (for switches with 8 ports equipped for Power over Ethernet (PoE) or the
switch with 24 100Base-FX/1000Base-SX SFP ports)
7 A (for switches with 24 ports equipped for PoE)
12 A (for switches with 48 ports equipped for PoE)
Specification
36 through 72 VDC
7 A maximum
190 W
69
