EX3200 Switch Hardware Guide
Table 54: Uplink Modules Connector Pinout Information (continued)
Pin Number
F18
F19
F20
G1
G2
G3
G4
G5
G6
G7
G8
G9
G10
G11
G12
G13
G14
G15
G16
G17
G18
G19
G20
H1
132
Pin Name
Uplink_P27_LED1
GND
POWER (12V)
GND
GND
XAUI0_RX1N
GND
XAUI0_RX3N
GND
XAUI1_RX1N
GND
XAUI1_RX3N
GND
SRX27N
GND
SRX25N
GND
GND
GND
Uplink_P25_LED0
GND
POWER (12V)
GND
Uplink_PD_Loopback
Copyright © 2016, Juniper Networks, Inc.
