CHAPTER 2

Chassis Components and Descriptions

Chassis Physical Specifications for EX3200 Switches

Table 5: Physical Specifications of the Switch Chassis

Description
Chassis height
Chassis width
Chassis depth
Weight
Copyright © 2016, Juniper Networks, Inc.
Chassis Physical Specifications for EX3200 Switches on page 7
Field-Replaceable Units in EX3200 Switches on page 8
Front Panel of an EX3200 Switch on page 9
Rear Panel of an EX3200 Switch on page 10
LCD Panel in EX3200 Switches on page 11
Uplink Modules in EX3200 Switches on page 15
Chassis Status LEDs in EX3200 Switches on page 18
Management Port LEDs in EX3200 Switches on page 20
Network Port LEDs in EX3200 Switches on page 21
The EX3200 switch chassis is a rigid sheet-metal structure that houses the hardware
components. Table 5 on page 7
switch chassis.
Value
1.75 in. (4.45 cm)
17.25 in. (43.82 cm)
19 in. (48.2 cm) with mounting brackets attached
Without power supply installed—17 in. (43.18 cm)
With power supply installed:
320 W AC power supply or 190 W DC power supply installed—17 in. (43.18 cm)
600 W or 930 W AC power supply installed—19.25 in. (48.9 cm)
320 W AC power supply: 2.5 lb (1.1 kg)
600 W and 930 W AC power supplies: 3.1 lb (1.4 kg)
190 W DC power supply: 2.5 lb (1.1 kg)
summarizes the physical specifications of the EX3200
7
