EX3200 Switch Hardware Guide
Table 12: Power Supply Rating and PoE Power Budget for EX3200 Switch Models
Switch Model Number
EX3200-24T
EX3200-48T
EX3200-24P
EX3200-48P
Related
Documentation

AC Power Supply LEDs in EX3200 Switches

Table 13: AC Power Supply LEDs

LED
AC OK
32
a maximum of 15.4 W per PoE port, if you connect a powered device that draws more
than 15.4 W, the PoE power budget might not be sufficient to supply a full 15.4 W to the
remaining PoE ports.
NOTE: Switches upgraded to Junos OS Release 11.1 from a previous release
require a separate upgrade of the PoE controller software to enable enhanced
PoE support.
Number of PoE-enabled
Ports
8
8
24
48
AC Power Cord Specifications for EX3200 Switches on page 70
AC Power Supply LEDs in EX3200 Switches on page 32
DC Power Supply LEDs in EX3200 Switches on page 33
Rear Panel of an EX3200 Switch on page 10
Field-Replaceable Units in EX3200 Switches on page 8
Power Specifications for EX3200 Switches on page 69
Prevention of Electrostatic Discharge Damage on page 269
Connecting AC Power to an EX3200 Switch on page 161
Connecting DC Power to an EX3200 Switch on page 163
Connecting Earth Ground to an EX Series Switch on page 155
Table 13 on page 32 describes the LEDs on the AC power supplies.
State and Description
Off—Disconnected from power or power is not coming into the power
supply.
On—Power is coming into the power supply.
Power Supply Rating
320 W
320 W
600 W
930 W
Copyright © 2016, Juniper Networks, Inc.
PoE Power Budget
130 W
130 W
410 W
740 W
