Mounting an EX3200 Switch on Two Posts in a Rack or Cabinet

144
Connecting AC Power to an EX3200 Switch on page 161
Connecting DC Power to an EX3200 Switch on page 163
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 175
Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 178
Clearance Requirements for Airflow and Hardware Maintenance for EX3200 Switches
on page 66
You can mount an EX3200 switch on two posts of a 19-in. rack (either a two-post or a
four-post rack) or a 19-in. cabinet by using the mounting brackets provided with the
switch. (The remainder of this topic uses "rack" to mean "rack or cabinet.")
You can mount the switch on four posts of a four-post rack by using the mounting brackets
provided with the separately orderable four-post rack-mount kit. See
EX3200 Switch on Four Posts in a Rack or Cabinet" on page
NOTE: If you need to mount the switch in a recessed position on either a
two-post rack or a four-post rack, you can use the 2-in.-recess front brackets
provided in the separately orderable four-post rack-mount kit.
Before mounting an EX3200 switch on two posts in a rack:
Verify that the site meets the requirements described in
for EX3200 Switches" on page
Place the rack in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
Read "General Safety Guidelines and Warnings" on page
to "Chassis Lifting Guidelines" on page
Remove the switch from the shipping carton (see
page 137).
Ensure that you have the following parts and tools available:
Phillips (+) screwdriver, number 2
2 mounting brackets and 8 mounting screws (provided in the accessory box shipped
with the switch)
Screws to secure the chassis to the rack (not provided)
2-in.-recess front brackets if you will mount the switch in a recessed position (brackets
are from the separately orderable four-post rack-mount kit).
"Site Preparation Checklist
57.
237, with particular attention
246.
"Unpacking an EX3200 Switch" on
Copyright © 2016, Juniper Networks, Inc.
"Mounting an
146.
