Table 11: Status LED on Network Ports (continued)
LED
Related
Documentation
Copyright © 2016, Juniper Networks, Inc.
LCD Indicator
Front Panel of an EX3200 Switch on page 9
Uplink Modules in EX3200 Switches on page 15
LCD Panel in EX3200 Switches on page 11
Chapter 2: Chassis Components and Descriptions
State and Description
The speed indicators for network ports on the SFP+ and SFP+
MACsec uplink module are:
Green—The speed of the transceiver installed in the port is the
same as the speed at which the uplink module port is configured
to operate.
Unlit—The speed of the transceiver installed in the port is not
the same as the speed at which the uplink module port is
configured to operate.
The speed of the XFP uplink module ports is always 10 Gbps, which
is also the speed of XFP transceivers, therefore, this LED is always
green on an XFP uplink module..
