EX3200 Switch Hardware Guide

Table 10: Link/Activity LED on Network Ports

LED
Link/Activity
22
Figure 12: LEDs on the Uplink Module Ports on the SFP+ and SFP+ MACsec
Uplink Modules

Figure 13: LEDs on the Uplink Module Ports on the XFP Uplink Module

Port 0
The LEDs labeled Link/Activity LED in
Figure 12 on page 22, and Figure 13 on page 22
Status LED in Figure 10 on page
Figure 13 on page 22 indicate the status of one of the four port parameters. The port
parameters are administrative status, duplex mode, Power over Ethernet (PoE) status,
and speed.
Table 10 on page 22 describes the Link/Activity LED.
Color
Green
Status LED Status LED
Port 1
Link/Activity Link/Activity
LED LED
Figure 10 on page
indicate link activity. The LEDs labeled
21, Figure 11 on page 21,
State and Description
Blinking—The port and the link are active, and there is link
activity.
On steadily—The port and the link are active, but there is no
link activity.
Off—The port is not active.
21, Figure 11 on page 21,
Figure 12 on page 22, and
Copyright © 2016, Juniper Networks, Inc.
