IDT PES64H16G2 Device Overview
Notes
PES64H16G2 User Manual
Signal Type
PE07TP[3:0] O PCI Express Port 7 Serial Data Transmit. Differential PCI Express trans-
PE07TN[3:0] mit pairs for port 7. When port 6 is merged with port 7, these signals
become port 6 transmit pairs for lanes 4 through 7.
PE08RP[3:0] I PCI Express Port 8 Serial Data Receive. Differential PCI Express receive
PE08RN[3:0] pairs for port 8.
PE08TP[3:0] O PCI Express Port 8 Serial Data Transmit. Differential PCI Express trans-
PE08TN[3:0] mit pairs for port 8.
PE09RP[3:0] I PCI Express Port 9 Serial Data Receive. Differential PCI Express receive
PE09RN[3:0] pairs for port 9. When port 8 is merged with port 9, these signals become
port 8 receive pairs for lanes 4 through 7.
PE09TP[3:0] O PCI Express Port 9 Serial Data Transmit. Differential PCI Express trans-
PE09TN[3:0] mit pairs for port 9. When port 8 is merged with port 9, these signals
become port 8 transmit pairs for lanes 4 through 7.
PE10RP[3:0] I PCI Express Port 10 Serial Data Receive. Differential PCI Express
PE10RN[3:0] receive pairs for port 10.
PE10TP[3:0] O PCI Express Port 10 Serial Data Transmit. Differential PCI Express
PE10TN[3:0] transmit pairs for port 10.
PE11RP[3:0] I PCI Express Port 11 Serial Data Receive. Differential PCI Express
PE11RN[3:0] receive pairs for port 11. When port 10 is merged with port 11, these sig-
nals become port 10 receive pairs for lanes 4 through 7.
PE11TP[3:0] O PCI Express Port 11 Serial Data Transmit. Differential PCI Express
PE11TN[3:0] transmit pairs for port 11. When port 10 is merged with port 11, these sig-
nals become port 10 transmit pairs for lanes 4 through 7.
PE12RP[3:0] I PCI Express Port 12 Serial Data Receive. Differential PCI Express
PE12RN[3:0] receive pairs for port 12.
PE12TP[3:0] O PCI Express Port 12 Serial Data Transmit. Differential PCI Express
PE12TN[3:0] transmit pairs for port 12.
PE13RP[3:0] I PCI Express Port 13 Serial Data Receive. Differential PCI Express
PE13RN[3:0] receive pairs for port 13. When port 12 is merged with port 13, these sig-
nals become port 12 receive pairs for lanes 4 through 7.
PE13TP[3:0] O PCI Express Port 13 Serial Data Transmit. Differential PCI Express
PE13TN[3:0] transmit pairs for port 13. When port 12 is merged with port 13, these sig-
nals become port 12 transmit pairs for lanes 4 through 7.
PE14RP[3:0] I PCI Express Port 14 Serial Data Receive. Differential PCI Express
PE14RN[3:0] receive pairs for port 14.
PE14TP[3:0] O PCI Express Port 14 Serial Data Transmit. Differential PCI Express
PE14TN[3:0] transmit pairs for port 14.
PE15RP[3:0] I PCI Express Port 15 Serial Data Receive. Differential PCI Express
PE15RN[3:0] receive pairs for port 15. When port 14 is merged with port 15, these sig-
nals become port 14 receive pairs for lanes 4 through 7.
PE15TP[3:0] O PCI Express Port 15 Serial Data Transmit. Differential PCI Express
PE15TN[3:0] transmit pairs for port 15. When port 14 is merged with port 15, these sig-
nals become port 14 transmit pairs for lanes 4 through 7.
Table 1.4 PCI Express Interface Pins (Part 2 of 2)
