IDT 89HPES64H16G2 User Manual page 261

IDT PCI to PCI Bridge and Proprietary Port Specific Registers
ACSCTL - ACS Control Register (0x326)
Bit Field
Field Name
0
1
2
3
4
5
6
15:7 Reserved
PES64H16G2 User Manual
Type
V Upstream Port:
RO
Downstream
Port:
RW
B Upstream Port:
RO
Downstream
Port:
RW
R Upstream Port:
RO
Downstream
Port:
RW
C Upstream Port:
RO
Downstream
Port:
RW
U Upstream Port:
RO
Downstream
Port:
RW
E Upstream Port:
RO
Downstream
Port:
RW
T Upstream Port:
RO
Downstream
Port:
RW
RO
Default
Value
0x0 ACS Source Validation Enable. When set, the port performs ACS
Source Validation.
NOTE: This field remains read-write (RW) for downstream ports,
even if the corresponding bit in the ACSCAP register is cleared.
0x0 ACS Translation Blocking Enable. When set, the port performs
ACS Translation Blocking.
NOTE: This field remains read-write (RW) for downstream ports,
even if the corresponding bit in the ACSCAP register is cleared.
0x0 ACS P2P Request Redirect Enable. When set, the port performs
ACS Peer-to-Peer Request Redirect.
NOTE: This field remains read-write (RW) for downstream ports,
even if the corresponding bit in the ACSCAP register is cleared.
0x0 ACS P2P Completion Redirect Enable. When set, the port per-
forms ACS Peer-to-Peer Completion Redirect.
NOTE: This field remains read-write (RW) for downstream ports,
even if the corresponding bit in the ACSCAP register is cleared.
0x0 ACS Upstream Forwarding Enable. When set, the port performs
ACS Upstream Forwarding.
NOTE: This field remains read-write (RW) for downstream ports,
even if the corresponding bit in the ACSCAP register is cleared.
0x0 ACS P2P Egress Control Enable. When set, the port performs
ACS Peer-to-Peer Egress Control.
NOTE: This field remains read-write (RW) for downstream ports,
even if the corresponding bit in the ACSCAP register is cleared.
0x0 ACS Direct Translated P2P Enable. When set, the port performs
ACS Direct Translated Peer-to-Peer control.
0x0 Reserved field.
16 - 51
Description
April 5, 2013
