IDT PCI to PCI Bridge and Proprietary Port Specific Registers
VCR0TBL1 - VC Resource 0 Port Arbitration Table Entry 1 (0x244)
Bit
Field
3:0
7:4
11:8
15:12
19:16
23:20
27:24
31:28
VCR0TBL2 - VC Resource 0 Port Arbitration Table Entry 2 (0x248)
Bit
Field
3:0
7:4
11:8
15:12
19:16
23:20
27:24
31:28
PES64H16G2 User Manual
Field Default
Type
Name Value
PHASE8 RW 0x0
PHASE9 RW 0x0
PHASE10 RW 0x0
PHASE11 RW 0x0
PHASE12 RW 0x0
PHASE13 RW 0x0
PHASE14 RW 0x0
PHASE15 RW 0x0
Field Default
Type
Name Value
PHASE16 RW 0x0
PHASE17 RW 0x0
PHASE18 RW 0x0
PHASE19 RW 0x0
PHASE20 RW 0x0
PHASE21 RW 0x0
PHASE22 RW 0x0
PHASE23 RW 0x0
Description
Phase 8. This field contains the port ID for the corresponding port
arbitration period.
Phase 9. This field contains the port ID for the corresponding port
arbitration period.
Phase 10. This field contains the port ID for the corresponding port
arbitration period.
Phase 11. This field contains the port ID for the corresponding port
arbitration period.
Phase 12. This field contains the port ID for the corresponding port
arbitration period.
Phase 13. This field contains the port ID for the corresponding port
arbitration period.
Phase 14. This field contains the port ID for the corresponding port
arbitration period.
Phase 15. This field contains the port ID for the corresponding port
arbitration period.
Description
Phase 16. This field contains the port ID for the corresponding port
arbitration period.
Phase 17. This field contains the port ID for the corresponding port
arbitration period.
Phase 18. This field contains the port ID for the corresponding port
arbitration period.
Phase 19. This field contains the port ID for the corresponding port
arbitration period.
Phase 20. This field contains the port ID for the corresponding port
arbitration period.
Phase 21. This field contains the port ID for the corresponding port
arbitration period.
Phase 22. This field contains the port ID for the corresponding port
arbitration period.
Phase 23. This field contains the port ID for the corresponding port
arbitration period.
