IDT 89HPES64H16G2 User Manual page 214

IDT PCI to PCI Bridge and Proprietary Port Specific Registers
CLS - Cache Line Size Register (0x00C)
Bit
Field
7:0
PLTIMER - Primary Latency Timer (0x00D)
Bit
Field
7:0
HDR - Header Type Register (0x00E)
Bit
Field
7:0
BIST - Built-in Self Test Register (0x00F)
Bit
Field
7:0
BAR0 - Base Address Register 0 (0x010)
Bit
Field
31:0
BAR1 - Base Address Register 1 (0x014)
Bit
Field
31:0
PES64H16G2 User Manual
Field Default
Type
Name Value
CLS RW 0x00
Field Default
Type
Name Value
PLTIMER RO 0x00
Field Default
Type
Name Value
HDR RO 0x01
Field Default
Type
Name Value
BIST RO 0x0
Field Default
Type
Name Value
BAR RO 0x0
Field Default
Type
Name Value
BAR RO 0x0
Description
Cache Line Size. This field has no effect on the bridge's function-
ality but may be read and written by software.
This field is implemented for compatibility with legacy software.
Description
Primary Latency Timer. Not applicable.
Description
Header Type. This value indicates a type 1 header with a single
function bridge layout.
Description
BIST. This value indicates that the bridge does not implement
BIST.
Description
Base Address Register. Not applicable.
Description
Base Address Register. Not applicable.
16 - 4 April 5, 2013
