IDT PCI to PCI Bridge and Proprietary Port Specific Registers
Bit
Field
8
10:9
11
12
13
14
15
RID - Revision Identification Register (0x008)
Bit
Field
7:0
CCODE - Class Code Register (0x009)
Bit
Field
7:0
15:8
23:16
PES64H16G2 User Manual
Field
Default
Type
Name
Value
MDPED
RW1C
0x0
DEVT
RO
0x0
STAS
RW1C
0x0
RTAS
RO
0x0
RMAS
RO
0x0
SSE
RW1C
0x0
DPE
RW1C
0x0
Field
Default
Type
Name
Value
RID
RWL
Field
Default
Type
Name
Value
INTF
RO
0x00
SUB
RO
0x04
BASE
RO
0x06
Master Data Parity Error Detected. This bit is set by the bridge
function if the PERRE bit in the PCI Command register (PCICMD)
is set to 0x1 and either of the following two conditions occurs: the
function receives a Poisoned Completion going Downstream, or
the function transmits a Poisoned Request Upstream.
DEVSEL# TIming. Not applicable.
Signaled Target Abort. This bit is set when the bridge completes
a posted or non-posted request with a completer-abort error. In the
switch, this bit is set when the bridge blocks a multicast TLP
received on its primary side.
Received Target Abort. Not applicable (the bridge function never
generates requests on its own behalf).
Received Master Abort. Not applicable (the bridge function never
generates requests on its own behalf).
Signaled System Error. This bit is set when the bridge function
sends a ERR_FATAL or ERR_NONFATAL message and the
SERR Enable (SERRE) bit is set in the PCICMD register.
0x0 - (noerror) no error.
0x1 - (error) This bit is set when a fatal or non-fatal error is sig-
naled.
Detected Parity Error. This bit is set by the bridge function when-
ever it receives a poisoned TLP on the primary side regardless of
the state of the PERRE bit in the PCI Command (PCICMD) regis-
ter.
-
Revision ID. This field contains the revision identification number
for the device.
Interface. This value indicates that the device is a PCI-PCI bridge
that does not support subtractive decode.
Sub Class Code. This value indicates that the device is a PCI-PCI
bridge.
Base Class Code. This value indicates that the device is a bridge.
16 - 3
Description
Description
Description
April 5, 2013
