5 General Specifications

Line power supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply voltage
AC line voltage low / line drop-out:
During low AC line voltage or a line drop-out, the FC continues until the intermediate circuit voltage drops below the minimum stop level, which
corresponds typically to 15% below the adjustable frequency drive's lowest rated supply voltage. Power-up and full torque cannot be expected at AC
line voltage lower than 10% below the adjustable frequency drive's lowest rated supply voltage.
Supply frequency
Max. imbalance temporary between line phases
True Power Factor (λ)
Displacement Power Factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≤10 hp [7.5 kW]
Switching on input supply L1, L2, L3 (power-ups) 15–100 hp [11–75 kW]
Switching on input supply L1, L2, L3 (power-ups) ≥125 hp [90 kW]
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600/ 690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency (0.33–10 hp [0.25–75 kW])
Output frequency (125–1350 hp [90–1000 kW])
Output frequency in flux mode (FC 302 only)
Switching on output
Ramp times
* Voltage and power dependent
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Starting torque (Variable torque)
Overload torque (Variable torque)
*Percentage relates to the nominal torque.
Digital inputs:
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic '0' PNP
Voltage level, logic '1' PNP
Voltage level, logic '0' NPN 2)
Voltage level, logic '1' NPN 2)
Maximum voltage on input
Pulse frequency range
(Duty cycle) Min. pulse width
Input resistance, R
i
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
5 General Specifications
200–240 V ±10%
FC 301: 380–480 V / FC 302: 380–500 V ±10%
FC 302: 525–600 V ±10%
FC 302: 525–690 V ±10%
50/60 Hz ±5%
3.0% of rated supply voltage
≥ 0.9 nominal at rated load
near unity (> 0.98)
maximum 2 times/min.
maximum 1 time/min.
maximum 1 time/2 min.
overvoltage category III/pollution degree 2
0 - 100% of supply voltage
FC 301: 0.2–1000 Hz / FC 302: 0–1000 Hz
0.01–3600 sec.
maximum 160% for 60 sec.
maximum 180% up to 0.5 sec.
maximum 160% for 60 sec.
maximum 110% for 60 sec.
maximum 110% for 60 sec.
FC 301: 4 (5) 1) / FC 302: 4 (6)
18, 19, 27 1) , 29
PNP or NPN
approx. 4 kΩ
5
0–800* Hz
0–300 Hz
Unlimited
*
*
*
*
1)
1) , 32, 33,
0–24 V DC
< 5 V DC
> 10 V DC
> 19 V DC
< 14 V DC
28 V DC
0–110 kHz
4.5 ms
5-1
