Danfoss VLT AutomationDrive FC 300 Instruction Manual page 62

4 How to Program
[20] Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
[29] Analog Input X48/2
3-16 Reference Resource 2
Option:
4
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
[20] * Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
[29] Analog Input X48/2
3-17 Reference Resource 3
Option:
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
[8] Frequency input 33
[11] * Local bus reference
[20] Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
[29] Analog Input X48/2
4-16
(General Purpose I/O Option Module)
(General Purpose I/O Option Module)
Function:
Select the reference input to be used for the second reference signal. par. 3-15
1 , par. 3-16 Reference Resource 2 and par. 3-17
reference signals. The sum of these reference signals defines the actual reference.
Function:
Select the reference input to be used for the third reference signal. par. 3-15
1 Reference Resource 2
, par. 3-16 and par. 3-17
reference signals. The sum of these reference signals defines the actual reference.
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
VLT ® AutomationDrive FC 300 Instruction
Reference Resource
Reference Resource 3 define up to three different
Reference Resource
Reference Resource 3
define up to three different
Manual
