Danfoss VLT AutomationDrive FC 300 Instruction Manual page 68

4 How to Program
[65] Reset Counter B
[70] Mech. Brake Feedback
[71] Mech. Brake Feedback inv.
[72] PID error inverse
[73] PID reset I-part
[74] PID enable
4
[80] PTC Card 1
4.3.3 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
cannot be adjusted while the motor is running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready / remote control
[4] Enable / no warning
[5] VLT running
[6] Running / no warning
[7] Run in range/no warning
[8] Run on reference / no warning
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedback range
[19] Below feedback low
4-22
Input for reset of counter B.
Brake feedback for hoisting applications: Set par 1-01 to [3]
Hoist mech brake Ref.
to [6]
Inverted brake feedback for hoisting applications
When enabled, it inverts the resulting error from the process PID controller. Available only if "Con-
figuration Mode" is set to "Surface Winder," "Extended PID Speed OL" or "Extended PID Speed CL."
When enabled, resets the I-part of the process PID controller. Equivalent to par. 7-40. Available
only if "Configuration Mode" is set to "Surface Winder," "Extended PID Speed OL" or "Extended PID
Speed CL."
When enabled, enables the extended process PID controller. Equivalent to par. 7-50. Available only
if "Configuration Mode" is set "Extended PID Speed OL" or "Extended PID Speed CL."
All digital inputs can be set to PTC card 1 [80]. However, only one digital input must be set to this
choice.
Terminal 27 Mode , and set the I/O function for terminal 29 in par. 5-02
Default for all digital outputs and relay outputs
The control card is ready. For example, Feedback from a drive where the control is supplied by an
external 24 V (MCB107) and the main power to drive is not detected.
The adjustable frequency drive is ready for operation and applies a supply signal on the control
board.
The adjustable frequency drive is ready for operation and is in Auto On mode.
Ready for operation. No start or stop command is been given (start/disable). No warnings are active.
Motor is running and shaft torque is present.
Output speed is higher than the speed set in par. 1-81
motor is running and there are no warnings.
Motor is running within the programmed current and speed ranges set in par. 4-50
Low Warning Speed High
to par. 4-53
Motor runs at reference speed. No warnings.
An alarm activates the output. There are no warnings.
An alarm or a warning activates the output.
The torque limit set in par. 4-16
The motor current is outside the range set in par. 4-18
Motor current is lower than set in par. 4-50
Motor current is higher than set in par. 4-51
Output frequency is outside the frequency ranges set in par. 4-52
par. 4-53 Warning Speed High
Output speed is lower than the setting in par. 4-52
Output speed is higher than the setting in par. 4-53
Feedback is outside the range set in par. 4-56
back High
.
Feedback is below the limit set in par. 4-56
MG.33.AG.22 - VLT
VLT ® AutomationDrive FC 300 Instruction
flux w/ motor feedback
Terminal 29 Mode
Min Speed for Function at Stop [RPM]
. There are no warnings.
Torque Limit Motor Mode
or par. 4-17 has been exceeded.
Current Limit
Warning Current Low
Warning Current High
.
Warning Speed Low
Warning Speed High
Warning Feedback Low
Warning Feedback Low
®
is a registered Danfoss trademark
Manual
; set par 1-72
. These parameters
. The
Warning Current
.
.
.
Warning Speed Low and
.
.
Warning Feed-
and par. 4-57
.
