VLT ® AutomationDrive FC 300 Instruction
Manual
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC brake inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
Preset ref. bit
Preset ref. 0
Preset ref. 1
Preset ref. 2
Preset ref. 3
Preset ref. 4
Preset ref. 5
Preset ref. 6
Preset ref. 7
(Default Digital input 27): Coasting stop, inverted input (NC). The adjustable frequency drive leaves
the motor in free mode. Logic '0' => coasting stop.
Reset and coasting stop Inverted input (NC). Leaves the motor in free mode and resets the adjust-
able frequency drive. Logic '0' => coasting stop and reset.
Inverted input (NC). Generates a stop in accordance with the quick-stop ramp time set in
Quick Stop Ramp Time
par. 3-81 . When motor stops, the shaft is in free mode. Logic '0' => quick
stop.
Inverted input for DC braking (NC). Stops motor by energizing it with a DC current for a certain time
DC Brake Current
period. See par. 2-01
only active when the value in par. 2-02
Stop Inverted function. Generates a stop function when the selected terminal goes from logical level
'1' to '0'. The stop is performed according to the selected ramp time (par. 3-42
Time Ramp 2 Ramp-down Time
, par. 3-52
Ramp-down Time
).
NOTE!
When the adjustable frequency drive is at the torque limit and has received a
stop command, it may not stop by itself. To ensure that the adjustable frequency
drive stops, configure a digital output to
this digital output to a digital input that is configured as coast.
(Default Digital input 18): Select start for a start/stop command. Logic '1' = start, logic '0' = stop.
The motor starts, if a pulse is applied for min. 2 ms. The motor stops when Stop inverse is activated.
(Default Digital input 19). Change the direction of motor shaft rotation. Select Logic '1' to reverse.
The reversing signal only changes the direction of rotation. It does not activate the start function.
Select both directions in par. 4-10
closed-loop.
Used for start/stop and for reversing on the same wire. Signals on start are not allowed at the same
time.
Disengages the counter-clockwise movement and allows for the clockwise direction.
Disengages the clockwise movement and allows for the counter-clockwise direction.
(Default Digital input 29): Use to activate jog speed. See par. 3-11
Shifts between external reference and preset reference. It is assumed that
Reference Function
been selected in par. 3-04
of the eight preset references is active.
Preset ref. bit 0,1, and 2 enables a choice between one of the eight preset references according to
the table below.
Same as Preset ref bit 0 [16].
Same as Preset ref bit 0 [16].
2
0
0
0
0
1
1
1
1
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
DC Brake Cut-in Speed [RPM]
to par. 2-03
DC Braking Time
is different from 0. Logic '0' => DC braking.
Ramp 3 Ramp-down Time
, par. 3-62
Torque limit & stop
Motor Speed Direction
. The function is not active in process
Jog Speed [Hz]
. Logic '0' = external reference active; logic '1' = one
1
0
0
1
1
0
0
1
1
4 How to Program
. The function is
4
Ramp 1 Ramp-down
Ramp 4
, par. 3-72
[27] and connect
.
External/preset
[1] has
0
0
1
0
1
0
1
0
1
4-19
