Danfoss VLT AutomationDrive FC 300 Instruction Manual page 70

4 How to Program
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
4
[75] Logic Rule 5
[80] SL Digital Output A
[81] SL Digital Output B
[82] SL Digital Output C
[83] SL Digital Output D
[84] SL Digital Output E
[85] SL Digital Output F
[120] Local reference active
[121] Remote reference active
[122] No alarm
[123] Start command active
4-24
See par. group 13-4*. If Logic Rule 0 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 1 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 2 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 3 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 4 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
See par. group 13-4*. If Logic Rule 5 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
SL Controller Action
See par. 13-52 . The output will go high whenever the Smart Logic Action [38]
Set dig. out. A
high is executed. The output will go low whenever the Smart Logic Action [32] Set
dig. out. A low is executed.
SL Controller Action
See par. 13-52 . The input will go high whenever the Smart Logic Action [39]
Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [33]
dig. out. A low
is executed.
SL Controller Action
See par. 13-52 . The input will go high whenever the Smart Logic Action [40]
Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [34]
dig. out. A low
is executed.
SL Controller Action
See par. 13-52 . The input will go high whenever the Smart Logic Action [41]
Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [35]
dig. out. A low
is executed.
SL Controller Action
See par. 13-52 . The input will go high whenever the Smart Logic Action [42]
Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [36]
dig. out. A low
is executed.
SL Controller Action
See par. 13-52 . The input will go high whenever the Smart Logic Action [43]
Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [37]
dig. out. A low
is executed.
Reference Site
Output is high when par. 3-13
Linked to hand auto
at the same time as the LCP is in hand on mode.
Reference site set in par. 3-13
Reference site: Local par. 3-13 [2]
Reference site: Remote par. 3-13 [1]
Reference site: Linked to Hand/ Auto
Hand
Hand -> off
Auto -> off
Auto
Reference Site = Remote
Output is high when par. 3-13
LCP is in [Auto on] mode. See above.
Output is high when no alarm is present.
Output is high when there is an active start command (i.e., via digital input bus connection or [Hand
on] or [Auto on]), and no stop or start command is active.
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
VLT ® AutomationDrive FC 300 Instruction
Reference Site
= [2] Local or when par. 3-13
Local reference Remote reference
active [120] active [121]
1 0
0 1
1 0
1 0
0 0
0 1
Linked to hand/auto
[1] or
Manual
Set
Set
Set
Set
Set
= [0]
[0] while the
