[47] Bus ctrl, 0 if timeout
[51] MCO controlled
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
[120] Local ref active
Controls output via bus. The state of the output is set in par. 5-90
the event of a bus timeout, the output state is set low (Off).
Active when a MCO 302 or MCO 305 is connected. The output is controlled from option.
See par. group 13-1* (Smart Logic Control). If Comparator 0 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-1* (Smart Logic Control). If Comparator 1 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-1* (Smart Logic Control). If Comparator 2 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-1* (Smart Logic Control). If Comparator 3 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-1* (Smart Logic Control). If Comparator 4 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-1* (Smart Logic Control). If Comparator 5 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-4* (Smart Logic Control). If Logic Rule 0 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-4* (Smart Logic Control). If Logic Rule 1 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-4* (Smart Logic Control). If Logic Rule 2 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-4* (Smart Logic Control). If Logic Rule 3 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-4* (Smart Logic Control). If Logic Rule 4 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. group 13-4* (Smart Logic Control). If Logic Rule 5 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
See par. 13-52 'Smart Logic Control Action'. Output A is low on Smart Logic Action [32]. Output A
is high on Smart Logic Action [38].
See par. 13-52 'Smart Logic Control Action'. Output B is low on Smart Logic Action [33]. Output B
is high on Smart Logic Action [39].
See par. 13-52 'Smart Logic Control Action'. Output C is low on Smart Logic Action [34]. Output C
is high on Smart Logic Action [40].
See par. 13-52 'Smart Logic Control Action'. Output D is low on Smart Logic Action [35]. Output D
is high on Smart Logic Action [41]
See par. 13-52 'Smart Logic Control Action'. Output E is low on Smart Logic Action [36]. Output E
is high on Smart Logic Action [42].
See par. 13-52 'Smart Logic Control Action'. Output F is low on Smart Logic Action [37]. Output F
is high on Smart Logic Action [43].
Output is high when par. 3-13 Reference Site = [2] Local or when par. 3-13 Reference Site = [0]
Linked to hand auto at the same time as the LCP is in hand on mode.
®
