VLT ® AutomationDrive FC 300 Instruction
Manual
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105), Relay
8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
Output is high when the adjustable frequency drive is running counter clockwise (the logical product
of the status bits 'running' AND 'reverse').
Output is high when the adjustable frequency drive is in hand on mode (as indicated by the LED
light above [Hand on]).
Output is high when the adjustable frequency drive is in hand on mode (as indicated by the LED
light above [Auto on]).
Function:
All digital and relay outputs are default set to "No Operation".
The control card is ready. For example, Feedback from a drive where the control is supplied by an
external 24 V (MCB107) and the main power to drive is not detected.
Drive is ready to operate. Line power and control supplies are OK.
The adjustable frequency drive is ready for operation and is in auto on mode.
Ready for operation. No start or stop commands have been applied (start/disable). No warnings are
active.
Motor is running, and shaft torque present.
Output speed is higher than the speed set in par. 1-81 Min Speed for Function at Stop [RPM]. The
motor is running and no warnings.
Motor is running within the programmed current and speed ranges set in par. 4-50
Low Warning Speed High
and par. 4-53
Motor runs at reference speed. No warnings.
An alarm activates the output. No warnings
An alarm or a warning activates the output.
The torque limit set in par. 4-16
Mode has been exceeded.
The motor current is outside the range set in par. 4-18
Motor current is lower than set in par. 4-50
Motor current is higher than set in par. 4-51
Output speed/frequency is outside the frequency ranges set in par. 4-52
Warning Speed High
par. 4-53 .
Output speed is lower than the setting in par. 4-52
Output speed is higher than the setting in par. 4-53
Feedback is outside the range set in par. 4-56
back High
.
Feedback is below the limit set in par. 4-56
Feedback is above the limit set in par. 4-57
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
. No warnings.
Torque Limit Motor Mode or par. 4-17
Current Limit
.
Warning Current Low
.
Warning Current High .
Warning Speed Low
Warning Speed High
Warning Feedback Low and par. 4-57
Warning Feedback Low
.
Warning Feedback High
.
4 How to Program
4
Warning Current
Torque Limit Generator
Warning Speed Low and
.
Warning Feed-
4-25
