Danfoss VLT AutomationDrive FC 300 Instruction Manual page 80

4 How to Program
4.4.3 2-** Brakes
Par. Parameter description
No. #
2-0* DC Brake
2-00 DC Hold Current
2-01 DC Brake Current
2-02 DC Braking Time
2-03 DC Brake Cut-in Speed [RPM]
2-04 DC Brake Cut-in Speed [Hz]
2-05 Maximum Reference
4
2-1* Brake Energy Funct.
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-13 Brake Power Monitoring
2-15 Brake Check
2-16 AC Brake Max. Current
2-17 Over-voltage Control
2-18 Brake Check Condition
2-19 Over-voltage Gain
2-2* Mechanical Brake
2-20 Release Brake Current
2-21 Activate Brake Speed [RPM]
2-22 Activate Brake Speed [Hz]
2-23 Activate Brake Delay
2-24 Stop Delay
2-25 Brake Release Time
2-26 Torque Ref
2-27 Torque Ramp Time
2-28 Gain Boost Factor
4-34
Default value 4-set-up
50 % All set-ups
50 % All set-ups
10.0 s All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
MaxReference (P303) All set-ups
null All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] Off All set-ups
[0] Off All set-ups
100.0 % All set-ups
[0] Disabled All set-ups
[0] At Power-up All set-ups
100 % All set-ups
ImaxVLT (P1637) All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0.0 s All set-ups
0.0 s All set-ups
0.20 s All set-ups
0.00 % All set-ups
0.2 s All set-ups
1.00 N/A All set-ups
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
VLT ® AutomationDrive FC 300 Instruction
FC 302 Change dur- Conver-
only ing opera- sion index
tion
TRUE 0
TRUE 0
TRUE -1
TRUE 67
TRUE -1
TRUE -3
TRUE -
TRUE 0
TRUE 0
TRUE -
TRUE -
TRUE -1
TRUE -
TRUE -
TRUE 0
TRUE -2
TRUE 67
TRUE -1
TRUE -1
TRUE -1
TRUE -2
TRUE -2
TRUE -1
TRUE -2
Manual
Type
Uint8
Uint16
Uint16
Uint16
Uint16
Int32
Uint8
Uint16
Uint32
Uint8
Uint8
Uint32
Uint8
Uint8
Uint16
Uint32
Uint16
Uint16
Uint8
Uint8
Uint16
Int16
Uint8
Uint16
