VLT ® AutomationDrive FC 300 Instruction
Manual
3-42 Ramp 1 Ramp-down Time
Range:
Application [Application dependant]
dependent*

4.3 Basic Set-up Parameters

0-02 Motor Speed Unit
Option:
[0] RPM
[1] * Hz
0-50 LCP Copy
Option:
[0] * No copy
[1] All to LCP
[2] All from LCP
[3] Size indep. of LCP
[4] File from MCO to LCP
[5] File from LCP to MCO
[6] Data from DYN to LCP
[7] Data from LCP to DYN
This parameter cannot be adjusted while the motor is running.
Function:
Enter the ramp-down time, i.e., the deceleration time from the synchronous motor speed n
RPM. Choose a ramp-down time such that no overvoltage arises in the inverter due to regenerative
operation of the motor, and such that the generated current does not exceed the current limit set
in par. 4-18 Current Limit . The value 0.00 corresponds to 0.01 s in speed mode. See ramp-up time
in par. 3-41 Ramp 1 Ramp-up Time
t dec s x n s RPM
Par
. 3 − 42 =
ref RPM
Function:
This parameter cannot be adjusted while the motor is running.
The display showing depends on settings in par. 0-02
Settings . The default setting of par. 0-02
on which region of the world the adjustable frequency drive is supplied to, but can be re-program-
med as required.
NOTE!
Changing the Motor Speed Unit
It is recommended to select the motor speed unit first before modifying other
parameters.
Selects display of motor speed variables and parameters (i.e. references, feedbacks and limits) in
terms of motor speed (RPM).
Selects display of motor speed variables and parameters (i.e., references, feedbacks and limits) in
terms of output frequency to the motor (Hz).
Function:
Copies all parameters in all set-ups from the adjustable frequency drive memory to the LCP memory.
Copies all parameters in all set-ups from the LCP memory to the adjustable frequency drive memory.
Copy only the parameters that are independent of the motor size. The latter selection can be used
to program several adjustable frequency drives with the same function without disturbing motor
data.
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
.
Motor Speed Unit
Motor Speed Unit and par. 0-03
will reset certain parameters to their initial value.
4 How to Program
to 0
s
4
and par. 0-03 Regional
Regional Settings depends
4-7
