VLT ® AutomationDrive FC 300 Instruction
Manual
3-10 Preset Reference
Array [8]
Range: 0-7
Range:
0.00 %* [-100.00 - 100.00 %]
Preset ref. bit
Preset ref. 0
Preset ref. 1
Preset ref. 2
Preset ref. 3
Preset ref. 4
Preset ref. 5
Preset ref. 6
Preset ref. 7
3-11 Jog Speed [Hz]
Range:
Application [Application dependant]
dependent*
3-15 Reference Resource 1
Option:
[0] No function
[1] * Analog input 53
[2] Analog input 54
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
Function:
2
0
0
0
0
1
1
1
1
Function:
The jog speed is a fixed output speed at which the adjustable frequency drive is running when the
jog function is activated.
Jog Ramp Time
See also par. 3-80
Function:
Select the reference input to be used for the first reference signal. par. 3-15
1 Reference Resource 2
, par. 3-16
reference signals. The sum of these reference signals defines the actual reference.
®
MG.33.AG.22 - VLT is a registered Danfoss trademark
1
0
0
1
1
0
0
1
1
.
Reference Resource 3
and par. 3-17
4 How to Program
4
0
0
1
0
1
0
1
0
1
Reference Resource
define up to three different
4-15
