Table Of Contents - Multitech MULTIMODEM MT5600ZDX Owner's Manual

Chapter 1 - Introduction and Description
Introduction .................................................................................................................... 5
Product Description ....................................................................................................... 5
What Is in Your Modem Package? ....................................................................... 8
How to Use This Manual ............................................................................................... 8
Chapter 2 - Installation
Installation ................................................................................................................... 10
Computer ............................................................................................................. 10
Serial Cable ......................................................................................................... 10
Telephone Line .................................................................................................... 11
Communications Software ................................................................................. 11
Installation Process ..................................................................................................... 12
Safety Warnings .................................................................................................. 12
LED Indicators ............................................................................................................. 15
Is Your MT5600ZDX Ready for Use? ......................................................................... 18
Operating Your MT5600ZDX ...................................................................................... 18
Simple Operations .............................................................................................. 19
Software Configuration ............................................................................................... 20
Hardware/Software Confirmation ....................................................................... 21
Troubleshooting ........................................................................................................... 22
None of the LEDs Light When the Modem Is On .............................................. 22
The Modem Does Not Respond to Commands ................................................ 23
The Modem Dials But Cannot Make a Connection ........................................... 25
The Modem Disconnects While Online .............................................................. 28
The Modem Cannot Connect When Answering ................................................ 28
Slow File Transfer ............................................................................................... 29
Losing Data ......................................................................................................... 29
Garbage Characters on the Monitor .................................................................. 30
Chapter 3 - AT Commands, S-Registers and Result Codes
AT Commands ............................................................................................................. 31
S-Registers .................................................................................................................. 51
Result Codes ............................................................................................................... 64
Chapter 4 - Testing Your Modem
Local Analog Loopback Test/V.54 Loop 3 .................................................................. 68
Digital Loopback Test/V.54 Loop 2 (Local/Manual) ................................................... 69
Digital Loopback Test/V.54 Loop 2 (Remote/Auto) .................................................... 70
Contents
iii
