- Page 1 ® MultiModem Data/Fax Modem MT5600BA-V92 Quick Start Guide Downloaded from Elcodis.com electronic components distributor...
- Page 2 MultiModem II Quick Start Guide Quick Start Guide MT5600BA-V92 Data/Fax Modem 82100142L Rev. C Copyright This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-Tech Systems, Inc. All rights reserved. Copyright © 2006-08 Multi-Tech Systems, Inc.
- Page 3 Introduction This Quick Start Guide will help you set up your modem. A User Guide containing detailed configuration information and a separate AT Commands Reference Guide can be found on the MultiModem II CD shipped with your modem. Safety Warnings •...
- Page 4 MultiModem II Quick Start Guide Connect the Modem to Your PC Plug one end of the serial cable into the modem’s RS-232 connector. Plug the other end into your PC’s serial port connector (COM1 or COM2). Connect the Modem to the Telephone Line (Dialup Connection) Plug one end of the phone cable into the modem’s LINE jack.
- Page 5 MultiModem II Quick Start Guide Step 2 – Install the Modem Driver If you use Windows 2000 or newer, you must install the modem driver. The modem driver tells Windows how to control the modem. If you use a Linux operating system, please refer to the User Guide for installation instructions.
- Page 6 MultiModem II Quick Start Guide Using the LCD Panel Country or Region Codes A list of country/region codes can be found on the Multi-Tech Web site at: http://www.multitech.com/PRODUCTS/Info/approvals Then click on global modems. The Global Modem Country Approvals page displays. On this page you can view approvals, configuration strings and responses by country and products.
- Page 7 MultiModem II Quick Start Guide Using the Global Wizard The Global Wizard configuration utility is recommended for computers running in Windows. The Wizard can configure your modem for a specific country or region with just a few mouse clicks. Insert the MultiModem Product CD into the CD-ROM drive. The Autorun dialog box appears.
- Page 8 Patents This device is covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; 5,724,356; 5,673,268; 5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; 5,559,793; 5,546,448; 5,546,395; 5,535,204; 5,500,859; 5,471,470; 5,463,616;...
