Canon iR C3380 series Service Manual page 451

Ref. Unit number Parts number
[17] UN14 FM2-2760
[18] UN15 FK2-0493
[19] UN16 FK2-0494
[20] UN17 FK2-0495
[21] UN18 RH7-7129
[22] UN19 RH7-7129
[23] UN20 FM2-0305
[24] UN21 FM2-0305
[25] UN22 FM2-2771
[26] UN23 FM2-2768
[27] UN24 FM2-8266
[28] - FM2-3221
[29] - FM2-9163
[30] - FM2-3677
[31] - FM2-9166
[32] - FM2-9166
[33] - FM2-3676
[34] - FM2-9161
[35] - FM2-9165
[36] - FK2-3077
[37] - FK2-3078
Description
AC driver PCB 230V
Registration detection sensor PCB
Batch detection sensor PCB
Environment sensor PCB
Transparency sensor PCB (emit)
Transparency sensor PCB (submit)
Cassette size detection switch PCB (CST1)
Cassette size detection switch PCB (CST2)
Cassette size relay PCB
Multi feeder size detection PCB
Process kit relay PCB
3-way unit driver PCB
Main controller PCB (S)
R-A PCB
PDRM-EF-A PCB (S)
PDRM-EF-A PCB (S)
SJ-A PCB
RB-A PCB
LANBAR-C PCB
Accessories power supply PCB 100/120V
Accessories power supply PCB 230V
Chapter 15
15-17
