EX 5/7/11 RT System
Table 5-3: Battery Recharge time to recover 90% of the rated backup time after discharge at full load.
Configuration for
2 hours backup time
EX 5 7 hours
EX 7 5 hours
EX 11 7 hours
5.4

System Short Circuit Protection

Short circuit current provided by EX 5/7/11RT in normal or battery mode:
EX5/7 RT 110A for 80ms
EX11 RT 190A for 80ms
5.5

Accessories Electrical Characteristics

EX RT Transformer
Nominal power
Nominal current
Input voltage
Output Voltage
Frequency
Isolation (EN 61558-1-2-4)
Operating temperature
Max. operating rel. humidity
Derating / altitude
Dimensions HxWxD (tower)
Dimensions HxWxD (rack 3U)
Weight
EX RT CLA module
AC input voltage
Input frequency
Battery charge current
5.6

Heat Rejection

Table 5-4: Full load heat rejection in BTU's/hr.
System
On-line
5kVA 1327
7kVA 1858
11kVA 2919
5.7

Environmental Characteristics

◗
The operating temperature is 0 to 40°C (8 hours at 45°C), however optimum operation is within the +20 to +25°C
range and at 5-95% humidity, non-condensing at altitude up to 3280ft without de-rating.
◗
The storage temperature : -20 to 40°C. Humidity : 5-95%, non condensing.
◗
Battery backup time is adversely affected by high and low temperatures. It is significantly reduced at tempera-
tures under 10°C. Above 25°C, battery service life is cut in half every 10°C. Above 40°C, battery manufacturers
no longer guarantee operation due to the risk of thermal runaway.
◗
Air enters through the front air vent grills and exits through the back. Always keep air vent grills unobstructed.
5 — 2
Configuration for
4 hours backup time
15 hours
12 hours
15 hours
11 kVA
63 A
208-240Vac
120/208/240Vac
50/60 Hz (+/-10%)
3.75 kV / 5 M ohms
From 0° to +40°C
95%
Pn-10% > 1000 m
17.5 x 5.15 x 25 inches (444 x 131 x 635 mm)
5.15 x 17.5 x 25 inches (131 x 444 x 635 mm)
151 lbs. (68.5 kg)
156-280 Volts AC
40-70 Hz
6 A DC
Operation Mode
On Battery
1944
2722
4278
Appendix
Configuration for
8 hours backup time
24 hours
20 hours
24 hours
86-86000-00 A01
