EX 5/7/11 RT System
Figure 2-12b: Step 3; Typical Straight Metal Conduit installation.
5.
Typical Straight Conduit Installation
OFF
O
(a)
NOTE: Place lug ring inside
the terminal block cover.
Screw coupling into lug ring.
Figure 2-12c: I/O Box Terminal Block Diagram.
Output
200/208/220/230/240Vac
L6 L5
2 — 14
OFF
O
(d)
Normal AC Source
200/208/220/230/240Vac
L2 L1 L1
Installation
5. Typical straight metal conduit
Installation.
a) Secure strain relief onto the
(c)
(e)
b) Insert three wire through flexible
(b)
c) Strip the insulation of each wire
CAUTION:
d) Secure three wires into the terminal
e) Twist the conduit onto the coupling
Bypass AC Source
200/208/220/230/240Vac
L4 L3
Jumper
terminal block cover as shown.
conduit.
back 1/2" to expose solid wire.
Always connect the
earth ground wire first.
block using guide printed on bottom
of I/O box.
body as shown.
86-86000-00 A01
