Battery Integration Kit With Casters; Input/Output Box - MGE UPS Systems EX 11RT Installation And User Manual

EX 5/7/11 RT System
1.5.5

Battery Integration Kit with Casters

(Part number 86005)
Battery Integration Kit is a cart, designed to hold up to 8 modules. It has swivel wheels with brakes, leveling feet,
seismic floor mount panels, plates to lock modules and hardware included. Modules not included.
Figure 1-10: Typical Battery Integration kit with casters setup.
(Modules Not Included In Kit)
1.5.6

Input/Output Box

Shipped with ferrules for stranded wire application.
- I/O Box 5/7kVA Part number 86009
- I/O Box 11kVA Part number 86010
