Hot Swapping the Battery Module

Figure 4-3: Rear view of the battery module.
Battery Module
42
14
4 — 6
Power Module
40
Maintenance
4.5.1

Disconnecting the Battery Module

1. Switch the battery circuit breaker(s)
OFF position.
2. Disconnect the cables
power module.
The battery module can be replaced.
The connected equipment is powered by the UPS,
but not protected.
It is also possible to replace battery pack instead of
battery module.
Contact your nearest after sales support service.
Always replace both battery
CAUTION:
packs with new ones.
To remove battery pack:
1. First, switch the battery circuit breaker(s) to the
OFF position.
See section 2.5 and follow instructions for battery
pack replacement.
4.5.2

Re-connecting the Battery Module

1. Reconnect the battery cables
the power module.
2. Switch the battery circuit breaker(s)
ON position.
14
to the
40 42
and from the
40 42
and to
14
to the
