Rear Panels

1.3.1

Power Module EX 5/7/11 RT

EX 5RT Power Module part number 86055
EX 7RT Power Module part number 86075
EX 11RT Power Module part number 86115
Figure 1-3: Rear panel of the Power Module.
4
5
9
10
11
1.3.2

Battery Module EXB 5/7/11 RT With Emergency Power Off (EPO) Function

Figure 1-4: Rear Panel of the Battery Module.
1 — 6
1
Slot for optional communication cards.
1
2
Communication port by relays (Dry contacts).
2
3
3
Remote Emergency Power Off communication port
(REPO).
4
Connectors for automatic detection of battery module(s).
5
RS232 communication port.
6
Battery/CLA module power connector.
6
7
Manual Bypass switch.
7
8
Normal AC source circuit breaker.
9
Knockout for entry of AC Output conduit.
8
10
Knockout for entry of Normal AC source conduit.
11
Knockout for entry of Bypass AC source conduit.
12
12
13
14
13
14
Introduction
Connectors for automatic detection of additional battery
module(s) (to the UPS or to other battery modules).
Battery power connectors (to the UPS or to other
battery modules).
Battery Circuit Breaker with Remote Emergency Power
Off (REPO) shunt trip.
EXB 5RT with EPO part number 86079
EXB 7RT with EPO part number 86079
EXB 11RT with EPO part number 86119
