A wide range of optional cards will allow your UPS to talk to nearly all equipment management systems, making
integration faster and easier. All these cards can plug directly into the UPS, saving time and money on your next
UPS project. (Meta UPS Card and U-Talk /Basic Acquisition Cards are used exclusively with Multi-slot.)
Dual U-Talk/Basic Card
ModBus Card
Dual COM Ports Card
USB Card
Dual Volt Free Contacts
Card for AS/400
Alarm Relay Card
XML-Web Card
SNMP-Web Card
86-86000-00 A01
(66060) Provides two communications ports that may be configured
for serial link or AS/400 type dry contacts.
(66061) Interface your UPS with a Building Management System.
(66066) This card has two independent RS232 communication ports
on which it can be connected. One for connecting monitoring software
(included) and one for remote control panel UPS control.
(66067) Take advantage of the latest and fastest communication
protocol for Microsoft Windows 2000/XP or Mac OSX.
(66068) The two ports are used to supply UPS status information
or one port can be used as a Remote Power Off (REPO) port.
(66069) Six output relays show UPS status and two status inputs are
used with the Galaxy 3000 UPS.
(66073) XML-Web Card acts as a web page for your UPS information.
Used along with XML-Client TM software, up to 50 servers or workstations will
be protected and can monitor the UPS with a simple web browser.
Security is handled with the SSL protocol, used by many websites to
safeguard sensitive password information.
(66074) The SNMP/Web 10/100BT communications card is
both an SNMP agent and an HTTP/Web server. Therefore, it
enables UPS supervision from any Network Monitoring
System using SNMP traps or simply from any web
browser (Internet Explorer, Netscape Navigator, etc.)
Orderly system shutdown of up to 32 protected servers can
be established using MGE's Solution-Pac/WAN software
suite.
