EX 5/7/11 RT System
1.1

System Electrical Characteristics

Table 3: Power Module Ratings
Part Number
Apparent Power, kVA
Active Power, kW
Input Current, A
Input Voltage, VAC
Output Current, A
Output Voltage, VAC
CAUTION
Table 4: Battery Module Ratings
Part Number
Battery Type
Battery Output Voltage
1.2

Standard Configurations

The EX 5/7/11 RT systems can be set up in tower and rack configurations.
1.2.1

Tower Configuration

Figure 1-1: Tower Configurations with Power Module, Battery Module, and optional Transformer Module.
Standard Configuration
POWER MODULE
(EX 5/7/11 RT)
1 — 4
86055 86075
5 7
4 4.9
25/24/23/ 35/34/32
22/21/20 31/30/28
200/208/220/ 200/208/220/
230/240/250 230/240/250
25/24/23/ 35/34/32
22/21/20 31/30/28
200/208/220/ 200/208/220/
230/240/250 230/240/250
Power Module is factory configured at 208Vac, 60 Hz input and output.
Input and Output of the UPS must always be the same.
86079 86119
12VDC/7Ah 12VDC/9Ah
240VDC 240VDC
Configuration with Transformer
BATTERY MODULE
(EXB 5/7/11 RT)
R T
E X B
1 1 R T
E X
ON
OFF
ups.c om
www .mge
om
.mge ups.c
www
EX RT Transformer
86115
10@ 200/208/250 VAC Output
11@ 220/230/240 VAC Output
8@ 200/208/250 VAC Output
7.3@ 220/230/240 VAC Output
50/48/50/48/46/40
200/208/220/230/240/250
50/48/50/48/46/40
200/208/220/230/240/250
BATTERY MODULE
or m er
Tr an sf
EX RT
om
.mge ups.c
www
Introduction
EX B RT
RT
EX 11
ON
OFF
om
.mge ups.c
www
om
.mge ups.c
www
POWER
MODULE
86-86000-00 A01
