EX 5/7/11 RT System
Table 3-3: ON/OFF features.
Display Factory setting
Cold start Disabled
Forced reboot Enabled
Automatic restart Enabled
Sleep mode Disabled
Remote Command Enabled
Table 3-4: Battery features.
Display Factory setting
Battery test Every week
Pre-Alarm 20%
Runtime choice UPS reads # and type
of battery
modules connected.
Battery deep discharge Enabled
protection
3.2.2

Accessing personalization through external software

Insert the Solution-Pac CD ROM in your CD drive.
◗
At the first Navigator Screen, select "Installation" and follow the instructions to install Personal
Solution-Pac for Windows.
◗
If nothing appears, launch startup.exe
◗
Then go to "Advanced settings" and "UPS settings".
Please note that the Linux/Unix/MacOS versions of Personal Solution-Pac do not include this feature.
3.2.3

Final startup sequence

Press the <ON> button more than 3 seconds.
◗
After UPS internal test sequence, the green LED
CAUTION
3 — 4
Options
Enabled
Disabled
Disabled
Enabled
Disabled
Options
No test/daily/monthly
0 to 100%
From 65 to 400 Ah
Disabled
During the restart, if the Bypass AC source is out of
tolerance, the UPS will generate an output
calibrated 10 msec output interrupt.
Operation
Comments
Start on battery.
Enables automatic restart of
the system even if normal AC
source is restored before the
end of the shutdown sequence.
UPS restarts automatically
when normal AC source
is restored.
Automatic shutdown on battery
if output load level <10%
Enables shutdown or restart
orders from software.
Comments
Low battery signal;1% increment
Requires EX 5/7/11RT CLA if
using options (see section 1.5.4
"Battery extensions cable kit")
If disabled, loss of
MGE UPS SYSTEMS,INC.
warranty.
15
goes on.
86-86000-00 A01
