1.2.2

Rack Configuration

Figure 1-2: Rack Configurations with Power Module, Battery Module, and Transformer Module.
Standard Configuration
Model
EX 5RT/7RT
EX 11RT
EXB 5 RT/ 7 RT
EXB 11RT
EX RT
Transformer
86-86000-00 A01
POWER MODULE
(EX 5/7/11 RT)
BATTERY MODULE
(EXB 5/7/11 RT)
Dimensions
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
Introduction
Installation and User Manual
Configuration with Transformer
ns fo rm er
EX RT Tra
com
www.m geups.
EX 11 RT
OFF
com
www.m geups.
EX B RT
com
www.m geups.
Weights
49.6 lbs (22.5 kg)
60.6 lbs (27.6 kg)
142 lbs (64.5 kg)
151 lbs (68.5 kg)
173 lbs (78.5 kg)
EX RT Transformer
POWER MODULE
(EX 5/7/11 RT)
ON
BATTERY MODULE
(EXB 5/7/11 RT)
1 — 5
