Power or Battery Module Rack Mounting

(optional rack mounting kits required, part number: 86001 and 86002)
The rails and necessary mounting hardware are supplied by MGE UPS SYSTEMS, INC.
Proceed as follows:
1. Attach both front mounting ear brackets
step, it is possible to adjust the position of both front mounting ears.)
26
2. Attach rails
3. Attach both rails to rear and front of rack chassis with supplied screws (as shown).
4. Use caution when sliding unit into rack mount, secure unit to rack with supplied screws. (For this step, it is
possible to adjust the position of both front mounting brackets.)
Figure 2-6: Rack mounting of the power module onto the rails.
3
2
86-86000-00 A01
24
together and secure with wing nuts, and finger tighten.
3
to power module or battery module with supplied screws. (For this
3
3
1
