- Page 1 www.mgeups.com SYSTEMS Pulsar EXtreme 2000/3000 VA Installation and user manual - Page 1 51033211EN/AC...
- Page 2 Production in an ISO 14001 certified factory, Recycling of Pulsar EXtreme at the end of its service life. To discover the entire range of MGE UPS SYSTEMS products and the options available for the Pulsar EXtreme range: We invite you to visit our Web site at www.mgeups.com (page: www.mgeups.com/products/pdt230/smallups/extreme/extrem10.htm),...
-
Page 3: En/Ac
Foreword Using this document Information may be found primarily by consulting: The contents, The index. Pictograms Important instructions that must always be followed. Information, advice, help. Visual indication. Action. Audio indication. In the illustrations on the following pages, the symbols below are used: LED off. -
Page 4: Table Of Contents
Contents Presentation Pulsar EXtreme range ......................... 7 Tower model ............................ 7 Rack model ............................. 7 Connection modules ........................8 Fault tolerant ........................... 8 Hot swap ............................8 Install ............................... 8 Back ............................. 9 Options ............................9 Transformer for galvanic isolation or earthing arrangement change ..........9 Battery extensions for UPS backup times of 66 minutes .............. - Page 5 Contents Failure of AC input power and operation on battery power ............ 21 Transfer to battery power ......................21 Threshold for the low-battery shutdown warning ................21 End of backup time ........................21 Sleep mode ........................... 21 Return of AC input power ......................21 Personalization ...........................
-
Page 6: Presentation
1. Presentation 1.1 Pulsar EXtreme range Tower model Dimensions in mm (H x W x D) EXtreme 2000 - 3000 443 x 173 x 465 Weight in kg Pulsar EXtreme 2000 Pulsar EXtreme 3000 Rack model Dimensions in mm (H x W x D) EXtreme 2000 - 3000 177 (4U) x 483 x 462 Weight in kg... -
Page 7: Connection Modules
1. Presentation 1.2 Connection modules Fault tolerant Socket for connection to AC-power source. Outlets for direct connection to protected equipment. Manual bypass switch. Input terminal block with cable clamp. Output terminal block with cable clamp. Hot swap Different types of sockets available on Fault tolerant and Hot swap connection modules: AC input cord Outlet sockets... -
Page 8: Connection Modules
1. Presentation 1.3 Back Slot for communications-card option. Battery module connector. Battery circuit breaker. Rating plate. Connector for connection modules. RS232 communications port. Page 8 - 51033211EN/AC... -
Page 9: Back
1. Presentation 1.4 Options Transformer for galvanic isolation or earthing arrangement change Pulsar EXtreme Transformer Nominal power 3 kVA Nominal current 16 A Input voltage 230V (+15%, -20%) Voltage drop < 3% Frequency 50/60 Hz (+/-10%) Isolation (EN 61558-1-2-4) 3.75 kV / 5 M ohms Operating temperature From 0°... -
Page 10: Cla Module (Long Backup Time Charger) For Backup Times Of 2 To 8 Hours
1. Presentation CLA module (Long backup time charger) for backup times of 2 to 8 hours Very long backup times, from 2 to 8 hours at full load, require a Pulsar EXtreme CLA module (2000VA or 3000VA). Visit our Web site: www.mgeups.com/products/pdt230/smallups/extreme/cla/cla2.htm. Pulsar EXtreme 2 5 A... -
Page 11: Control Panel
1. Presentation 1.5 Control panel Alarms % battery % load remaining UPS overload 100% 100% Electronics fault Battery fault Ambient temp. > 40°C Hold down to display percent load. Lamp test or buzzer OFF. Operation on manual bypass. Operation on automatic bypass. bypass Operation in ON-LINE mode. -
Page 12: Unpacking And Checks
2. Installation 2.1 Unpacking and checks Tower model RS 232 communications cable. CD ROM with "Solution Pac" and "UPS Driver" softwares. Quick Start documentation. Installation and user manual. Electrical power cord (except INSTALL version and version with IEC outlets). Page 12 - 51033211EN/AC... -
Page 13: Rack Model
2. Installation Rack model RS 232 communications cable. CD ROM with "Solution Pac" and "UPS Driver" softwares. Quick Start documentation. Installation and user manual. Electrical power cord (except INSTALL version and version with IEC outlets). Telescopic rails for mounting in 19" bay with mounting hardware. - Page 13 51033211EN/AC... -
Page 14: Installation Of The Rack Version
2. Installation 2.2 Installation of the rack version Rack mounting diagram with rails. The rails and the necessary mounting hardware are supplied with the UPS in the package. Page 14 - 51033211EN/AC... -
Page 15: Connection To The Rs 232 Communications Port (Optional)
2. Connect the RS 232 communications cable to the RS 232 communications port on the UPS. The UPS can now communicate with all MGE UPS SYSTEMS supervision, set-up or safety software. Pin-out diagram for the RS 232 communications port on the UPS. -
Page 16: Securing And Connecting The Connection Modules
2. Installation 2.5 Securing and connecting the connection modules Securing the connection modules 1. Insert the connection module in the connector 2. Secure the connection module to the UPS using the two screws Fault tolerant Before carrying out any connections, check that the battery circuit breaker is OFF and that the electrical power cord to the AC-power source is disconnected. -
Page 17: Hot Swap
2. Installation Hot swap Before carrying out any connections, check that the battery circuit breaker is OFF and that the electrical power cord to the AC-power source is disconnected. Connection of equipment to outlets Plug your equipment into the outlets Connection of equipment to a terminal block: This type of connection must be carried out by qualified electrical personnel. -
Page 18: Install
2. Installation Install This type of connection must be carried out by qualified electrical personnel. Before carrying out any connections, check that the battery circuit breaker is OFF and that the upstream protection devices (AC distribution system) are open (OFF). The overall cable diameter and the cross-sectional area of the three wires depends on the UPS rating. -
Page 19: Operation
3. Operation 3.1 ON-LINE operating mode This is the normal operating mode for the UPS. bypass Two possible cases: is ON: AC input power is available. Power is drawn from the distribution system and supplied to the protected equipment via the UPS. is ON: AC input power is not available. -
Page 20: Start-Up
3. Operation 3.2 Start-up Prior to initial start-up, check the UPS voltage settings. The frequency of the output voltage (50 or 60 Hz) is automatically set to that of the input source. 1. Close the upstream device (ON position) controlling the supply of AC power to the UPS. -
Page 21: Failure Of Ac Input Power And Operation On Battery Power
3. Operation 3.4 Failure of AC input power and operation on battery power AC input power is not available, the battery steps in to supply the protected equipment. Transfer to battery power When AC-power source goes outside tolerances or fails completely, LED goes ON and the buzzer beeps three times. -
Page 22: Personalization
3. Operation 3.5 Personalization Function Personalization parameters can be set and modified using the "UPS Driver" software installed on a computer that is connected to the UPS (see section 2.3 Connection to the RS 232 communications port). Check that the RS 232 cable is correctly connected and that the battery circuit breaker is closed. -
Page 23: Battery" Tab
3. Operation "Battery" tab Personalizable function Default setting Options Once a week "Battery test" intervals Every day Once a month No test "Low-battery shutdown warning" threshold 20% remaining battery 40% remaining battery backup time backup time Charger Standard CLA (2, 4 or 8 hours) "Output"... -
Page 24: Shutdown
3. Operation 3.6 Shutdown Shutdown of connected equipment 1. Press button (return to the OFF position). The connected equipment is no longer supplied with power, but the battery is maintened charged if AC-power source is present. If the AC source fails, even though the connected equipment is no longer supplied, the UPS operates on battery power and therefore reduces the available backup time. -
Page 25: Maintenance
4. Maintenance 4.1 Troubleshooting If one or more LEDs flash, there is a operating anomaly or an alarm. 14 15 16 If a LED flashes, the bargraph data is no longer displayed. Troubleshooting not requiring MGE after-sales support Indication Signification Correction LEDs The UPS has detected a problem... - Page 26 4. Maintenance Troubleshooting requiring MGE after-sales support Indication Signification Correction flashes and the buzzer UPS electronics have detected a UPS For UPSs equipped with Hot beeps. fault. swap or Install connection Depending on the UPS personalization modules, follow the UPS parameters (see section 3.5), there are replacement procedure (see two possibilities:...
-
Page 27: Ups Replacement
4. Maintenance 4.2 UPS replacement Fault-tolerant connection module Before carrying out this operation, the supply of power to the connected equipment must be cut. The equipment will therefore no longer be powered. Disconnection: 1. Shut down the UPS by pressing button (return to the OFF position). -
Page 28: Hot-Swap And Install Connection Modules
4. Maintenance Hot-swap and Install connection modules Disconnection: Before turning the switch, see the manual 1. Turn the manual bypass switch , located behind the UPS (see section 2.5), from the NORMAL NORMAL BY-PASS to the intermediate position. 2. Check that LED is ON before continuing to the BYPASS position. - Page 29 4. Maintenance Reconnection: 1. Insert the connection module in the connector and secure using the two screws 2. Switch the battery circuit breaker(s) to the ON position and check that LED is ON. Check that UPS personalization settings still correspond to the equipment to be supplied (see section 3.5).
-
Page 30: Environment
It was manufactured in a factory certified ISO 14001. UPS recycling at the end of service life: MGE UPS SYSTEMS undertakes to recycle, by certified companies and in compliance with all applicable regulations, all UPS products recovered at the end of their service life (contact your branch office). -
Page 31: Glossary
6. Appendices 6.1 Glossary Authorized voltage Upper and lower voltage thresholds within which the UPS can operate range for transfer to on the automatic bypass in the event of a UPS fault or overload. bypass if fault or overload Automatic bypass Automatic switch controlled by the UPS, used to connect the equipment directly to the AC-power source. - Page 32 6. Appendices Out of tolerance The AC input source is either absent or its voltage or frequency is outside the set limits. Hot swap Connection module (with manual bypass) offering a socket for connection to the AC-power source and outlets or a terminal block for connection to the equipment.
-
Page 33: Index
6. Appendices 6.2 Index AC power LEDs Failure ............21 Lamp test ............11 Frequency tolerance ........23 Rated frequency ..........23 Rated voltage ..........23 Mode Return ............21 ON LINE mode ........11, 19 Bargraph .............. 20 Overload ........... 11, 23, 25 Battery Battery test ............ - Page 34 Page 34 - 51033211EN/AC...
