  • Page 1 EXL 1000 Extended Battery Cabinet Installation Manual...

  • Page 2: Important Safety Instruction

    IMPORTANT SAFETY INSTRUCTION SAVE THESE INSTRUCTIONS — This manual contains important instructions for Extended Battery Cabinet Installation that must be followed during installation, operation and maintenance of the equipment. WARNING OPENING ENCLOSURES EXPOSES HAZARDOUS VOLTAGES. ALWAYS REFER SERVICE TO QUALIFIED PERSONNEL ONLY. NOTE As standards, specifications and designs are subject to change, please ask for confirmation of the information given in this...
  • Page 3 EXL 1000 Extended Battery Cabinet Installation Manual For service call 1-800-438-7373 86-153226-01 B00 11/97 Copyright © 1997 MGE UPS Systems, Inc. All rights reserved. Printed in U.S.A. MGE UPS Systems 1660 Scenic Avenue Costa Mesa, CA 92626 (714) 557-1636 86-153226-01...
  • Page 4 The liability of MGE UPS Systems, Inc. hereunder is limited to replacing or repairing at MGE UPS Systems, Inc.’s factory or on the job site at MGE UPS Systems, Inc.’s option, any part or parts which are defective, including labor, for a period of 24 months from the date of purchase.

  • Page 5: Table Of Contents

    1-1 ....Location of bolts holding Extended battery cabinet to shipping base, and EXL 1000 ramp for lowering 1 — 2 1-2 ....Maintenance Bypass Switches 1 —...

  • Page 6: How To Use This Manual

    EXL 1000 UPS Extended Battery Cabinet How to use this manual This manual is designed for ease of use and easy location of information. This manual uses Note boxes to convey important information. Note boxes come in four varieties: WARNING...

  • Page 7: Scope

    Table Tools & Material needed to install EXL 1000 Extended Battery cabinets: E X L 1 0 5 6 , E X L 1 0 5 7 , E X L 1 0 7 6 , E X L 1 0 7 7 , E X L 11 0 1 , E X L 11 0 2...

  • Page 8: Location Of Bolts Holding

    L o c a t i o n o f b o l t s h o l d i n g e x t e n d e d b a t t e r y c a b i n e t to shipping base, and EXL 1000 ramp for lowering A ramp is included with the EXL 1000 UPS to facilitate bringing that unit from it’s shipping base to floor level. Use this same ramp to move the extended battery cabinet off its shipping base.

  • Page 9: Wiring Connections

    All wire gauges and installation should be performed as per local and NEC codes. EXL 1000 UPS output 208 or 240 VAC phase to phase. There is no neutral. Battery terminal blocks, located at rear panel of UPS, are provided on the back of the UPS for connection of one or more external battery cabinets.

  • Page 10: Prior To Connection

    EXL 1000 UPS Extended Battery Cabinet Figure L o c a t i o n o f M a i n t e n a n c e B y p a s s S w i t c h...

  • Page 11: Preparing The Conduit Wire

    Installation manual Figure P r e p a r i n g t h e c o n d u i t w i r e b e f o r e c o n n e c t i n g t o U P S 1.3.3 Wiring the extended The procedure to follow in the electrical installation of the...
  • Page 12 EXL 1000 UPS Extended Battery Cabinet Figure W i r i n g t h e e x t e n d e d b a t t e r y c a b i n e t t o t h e U P S l a n d i n g...

  • Page 13: Emergency Off Function

    C o n n e c t i o n d i a g r a m f o r M X s h u n t t r i p t o t e r m i n a l b l o c k X R 3 NOTE If the EXL 1000 UPS was not facory configured for the additional battery cabinets, the new configuration must be set by an MGE UPS Systems After-Sales Support technician.
  • Page 14 EXL 1000 UPS Distribution Cabinet (This page left blank intentionally) 1 — 8 86-153226-01...
