w w w . m g e u p s . c o m
EX 5/7/11RT Systems
Installation and User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX-11RT and is the answer not in the manual?

Questions and answers

Related Manuals for MGE UPS Systems EX-11RT

Summary of Contents for MGE UPS Systems EX-11RT

  • Page 1 w w w . m g e u p s . c o m EX 5/7/11RT Systems Installation and User Manual...

  • Page 3: Revision History

    R e v i s i o n : A 0 1 A 0 2 A 0 3 B 0 0 Copyright © 2006 MGE UPS SYSTEMS, INC. All rights reserved. Printed in U.S.A. MGE UPS SYSTEMS, INC. 1660 Scenic Avenue Costa Mesa, CA 92626...
  • Page 4 EX 5/7/11RT Systems (This page left blank intentionally) 86-86000-00 B00...

  • Page 5: Table Of Contents

    section description ......... . .page Revision History .
  • Page 6 EX 5/7/11RT Systems section description ......... . .page Section 2 Setup and Installation Scope .
  • Page 7 section description ......... . .page Section 4 Maintenance Scope .
  • Page 8 EX 5/7/11RT Systems Figures figure description ..........page 1-1: Tower Configuration with Power Module, Battery Module, and optional Transformer Module.
  • Page 9 Figures (continued) figure description ..........page 3-1: Initial Startup Display.

  • Page 10: Important Safety Instructions

    IEEE 587-1980/ANSI C62.41 1980 Standards for Surge Withstand Ability ◗ FCC rules and regulations of Part 15, Subpart J, Class A ◗ UL listed under 1778, Standards for Uninterruptible Power Supply Equipment ◗ IEC 61000-4-2 (ESD): level 4. ◗ IEC 61000-4-3 (Radiated field): level 3.

  • Page 11: Caution: Safety Of Persons

    UPS recycling at the end of service life: MGE UPS SYSTEMS, INC. undertakes to recycle, by certified companies and in compliance with all applicable regulations, all UPS products recovered at the end of their service life (contact your MGE UPS SYSTEMS, INC. branch office).

  • Page 12: Caution: Record All Serial Numbers

    EX 5/7/11RT Systems CAUTION: Record All Serial Numbers! RECORD ALL SERIAL NUMBERS FOR EX 5/7/11RT AND ACCESSORIES. THESE SERIAL NUMBERS WILL BE REQUIRED IF YOUR SYSTEM NEEDS SERVICE. KEEP THIS MANUAL IN A PLACE WHERE YOU CAN REFERENCE THE SERIAL EX 5RT System Power Module SERIAL NUMBER: ___________________________________________________ Battery Module SERIAL NUMBER: ____________________________________________________...

  • Page 13: Symbol Usage

    Symbol Usage This manual uses the following icon symbols with text to convey important information and tips. WARNING CAUTION IMPORTANT NOTE Visual Action Section Descriptions Introduction Introduction is a general description of system configurations of the EX 5/7/11RT, and its mechanical electrical characteristics.
  • Page 14 EX 5/7/11RT Systems (This page left blank intentionally) 86-86000-00 B00...

  • Page 15: Ex Rt Model Descriptions And Contents

    Thank you for selecting an MGE UPS SYSTEMS, INC. (MGE) product to protect your electrical equipment. The product you selected is a part of the EX RT series. The EX RT series is a family of Uninterruptible Power Supply (UPS) designed to provide safe, and reliable AC power backup for sensitive electrical equipment. To discover the entire range of MGE products, we invite you to visit our website at www.mgeups.com or contact your representa-...

  • Page 16: Optional Accessories (See Section 1.5 For Description)

    EX 5/7/11RT Systems Table 1-2: Optional Accessories (See section 1.5 for description) Part Number 86001 86002 86005 86006 86008 86009 86010 86012 86013 86207 86209 86211 86213 86215 86216 86217 1 — 2 Description Rail Kit for Power Module EX 5/7/11RT Rail Kit for Battery/Transformer/CLA Module Battery Integration Kit with Casters Battery Extension Cable Kit...

  • Page 17: Transformer Module Characteristics Ratings

    System Electrical Characteristics Table 1-3: UPS Characteristics System Ratings. Input Power Voltage Rating (VAC) 5 kVA 7 kVA 11 kVA Table 1-4: Transformer Module Characteristics Ratings. Input Voltage (VAC) Output Voltage (VAC) Max. Output Current (A) CAUTION Power Module is factory configured at 208Vac, 60 Hz input and output. Without transformer, Input and Output of the UPS must always be the same.

  • Page 18: And Optional Transformer Module

    EX 5/7/11RT Systems Table 1-5: Battery Module Ratings. Part Number Battery Type Battery Output Voltage Standard Configuration The EX 5/7/11RT systems can be set up in tower or rack configurations. 1.2.1 Tower Configuration Figure 1-1: Tower Configuration with Power Module, Battery Module, and optional Transformer Module. 1 —...

  • Page 19: And Optional Transformer Module

    1.2.2 Rack Configuration Figure 1-2: Rack Configuration with Power Module, Battery Module, and optional Transformer Module. Standard Configuration POWER MODULE (EX 5/7/11 RT) BATTERY MODULE (EXB 5/7/11 RT) Table 1-6: System Dimensions and Weights. Model EX 5/7RT Power Module EX 11RT Power Module EXB 5/7RT Battery Module EXB 11RT Battery Module EX RT Transformer Module...

  • Page 20: Rear Panel Of The Battery Module

    EX 5/7/11RT Systems Rear Panel Components 1.3.1 Power Module EX 5/7/11 RT Figure 1-3: Rear panel of the Power Module. 1.3.2 Battery Module EXB 5/7/11RT With Remote Emergency Power Off (REPO) Function Figure 1-4: Rear Panel of the Battery Module. 1 —...

  • Page 21: Rear Panel Of The Optional Transformer Module. (Pn 86211)

    1.3.3 EX RT Transformer Module Figure 1-5: Rear Panel of the optional Transformer Module. (PN 86211) Load 4: 4 NEMA 5-15/20R, 120Vac Load 4 Circuit Breaker AC Input Transformer I/O Box AC Output Transformer Protect Power Module Display and Control Panel Figure 1-6: View of typical control panel interface.

  • Page 22: Optional Accessories

    EX 5/7/11RT Systems Optional Accessories Optional Accessories describes the options available for upgrades and enhancement of the EX 5/7/11RT systems. Detailed installation of the unit is described in following sections. To ensure a successful installation, all procedures should be followed in their correct sequence. Note that any unauthorized installation may cause damage to the UPS(s) and void the MGE warranty.

  • Page 23: Typical Back-Up Time With Multiple Exb's At Full Load

    EX 5/7/11RT Systems 1.5.3 Multiple Battery Module Backup Time at Full Load Standard EX 5/7/11RT systems (one Power Module, and one Battery Module), offers a standard backup time of 5 to 12 minutes at full load. To increase backup time, it is possible to connect up to 5 additional Battery Modules to the standard system. See section 2.8 for connections between standard system and Battery Module (EXB 5/7/11RT) Figure 1-9: Typical back-up time with multiple EXB’s at full load.

  • Page 24: Battery Integration Kit With Casters

    EX 5/7/11RT Systems 1.5.5 Battery Integration Kit with Casters (Part number 86005) Battery Integration Kit is a cart, designed to hold up to 8 modules. It has swivel wheels with brakes, leveling feet, seismic floor mount panels, plates to lock modules and hardware included. Modules not included. Figure 1-10: Typical Battery Integration kit with casters setup.

  • Page 25: Typical Transformer Module Contents And Connections

    EX 5/7/11RT Systems 1.5.7 Transformer Module - For use with EX 5/7/11RT Power Module This module provides isolated 120/208/240Vac outputs. Figure 1-11: Typical Transformer Module contents and connections. EX RT Transformer Module Contents AC NORMAL INPUT 86-86000-00 B00 Transformer Module Quick Start Manual Transformer Cable...

  • Page 26: Cla Module Contents And Connections

    EX 5/7/11RT Systems 1.5.8 CLA Charger Module Extended back-up time (up to 8 hours at full load) requires a high power battery cabinet connected to the EX 5/7/11RT via the CLA Module. IMPORTANT The CLA can not be used to charge the Battery Module (EXB). It is designed to charge the customer provided high power battery cabinet.

  • Page 27: Setup And Installation

    Scope Setup and Installation guides the user through tools and equipment required for connecting the EX 5/7/11RT and battery installation or replacement. Included are assembly instructions, power cable connections with wire diagrams for configuring the product to hardware specifications. Unpacking and Parts Check Once the EX 5/7/11RT systems has been inspected and received from the shipping courier, the unit should be moved to a position as close to the final installation location as possible.

  • Page 28: Contents Of Ex 5/7/11Rt Power Module

    EX 5/7/11RT Systems Contents of Standard EX 5/7/11RT Systems Contents of EX 5/7/11RT Power Module: (PN 86215 / 86216 / 86217) EX 5/7/11RT Power Module. Two sets of tower stands. RS232 communication cable. Product documentation. Input/Output Box. (PN 86009 for EX 5/7RT; 86010 for EX 11RT) Solution-Pac 2 CD.

  • Page 29: Contents Of Exb 5/7/11Rt Battery Module

    Contents of EXB 5/7/11RT Battery Module: (PN 86207 /86209) Stabilizer Bracket and hardware. EXB 5/7/11RT. Tower stand expanders. Battery Power cable. Battery/EX RT Transformer/CLA Module rail kit, PN 86002. Battery detection cable. EXB Documentation. Bezel hex drive. Figure 2-2: Contents of EXB 5/7/11RT Battery Module. E X B - EXB 5RT Battery Module Part number: 86207.

  • Page 30: Optional Transformer Module

    EX 5/7/11RT Systems Installation in Tower Configuration Follow the numerical sequence to assemble tower stands and tower stand expanders, shown in Figure 2-3. Figure 2-3: Tower Configuration of Standard System and Optional Transformer Module. Tower Configuration with Standard System Tower Configuration with Optional Transformer Module geups.c www.m 2 —...

  • Page 31: Installation In Rack Mounting Configuration

    Installation in Rack Mounting Configuration 2.4.1 Adjustment of front panel logo and control panel for rack orientation. NOTE If system includes the Transformer Module, we recommend to mount the Battery Module on the bottom, then mount the Power Module above the Battery Module and mount the Transformer Module on top for optimum stability.

  • Page 32: Accessing Battery Pack

    EX 5/7/11RT Systems 2.4.2 Prepare Battery Module for Rack Mounting IMPORTANT This step requires two people. The Battery Module is very heavy (151 lbs.). To ease its rack mounting, you can remove the battery pack from the Battery Module, as explained below. Proceed as follows: 1.

  • Page 33: Power, Battery, Transformer, And Cla Charger Module Rack Mounting

    2.4.3 Power, Battery, Transformer, and CLA Charger Module Rack Mounting The following steps apply to all modules. For simplicity, only Power Module is shown. Proceed as follows: 1. Attach both front mounting ear brackets adjust the position of both front mounting brackets.) 2.

  • Page 34: Input/Output Box Bracket System

    EX 5/7/11RT Systems NOTE: This step is unique to the Power Module. It involves the installation of the I/O Box Bracket System. The I/O Box bracket system keeps the I/O Box stationary while hot swapping the Power Module. It will then be easier to slide the replacement module into the connectors of the I/O Box.

  • Page 35: Rs232 Communication Cable Connection

    ◗ The Dry Contact Port (formerly AS400) and more. ◗ The slot is compatible with most MGE UPS SYSTEMS, INC. Transverse communication card (see section 2.7.3 or check www.mgeups.com for the complete list of compatible cards). 2.5.1 Connecting the RS232 Communication Port 1.

  • Page 36: Relay Pin Connections For Communication Port

    EX 5/7/11RT Systems 2.5.2 Connecting the Dry (Relay) Contact Communication Port The system status is indicated by the connection of common pin (Pin 5) to the appropriate pins. Refer to the pin explanations below for details. Figure 2-9: Relay Pin Connections for Communication Port. common When the status is active, the contact between the common (Pin 5) and the relevant information...
  • Page 37 A wide range of optional cards will allow your UPS to talk to nearly all equipment management systems, making integration faster and easier. All these cards can plug directly into the UPS, saving time and money on your next UPS project. (Meta UPS Card and U-Talk/Basic Acquisition Cards are used exclusively with Multi-slot.) Dual U-Talk/Basic Card JBus Card Dual port SHUT Card...

  • Page 38: Using A Contact Normally Open Switch

    EX 5/7/11RT Systems Remote Emergency Power Off (REPO) Communication Port The end user is responsible for the installation of a Remote Emergency Power Off function. Installation must be carried out in compliance with local code regulations. To shutdown the entire system completely in case of emergency: ◗...

  • Page 39: Power Module I/O Box Terminal Block Diagram

    System Connections WARNING This type of connections must be carried out by qualified electrical personnel. Before carrying out any connections, check that battery circuit breaker OFF and that the upstream protection devices (Normal and Bypass AC sources) are open (OFF/OPEN). 2.7.1 Connections with Common Normal and Bypass AC Sources (Single Mains) Figure 2-11: Power Module I/O Box Terminal Block Diagram.

  • Page 40: Normal Ac Input And Output Cables Installation

    EX 5/7/11RT Systems Proceed as follows: 1. For normal AC input, make connections to L1, L2 and Bypass AC input. Make connections to CAUTION: Always connect the earth ground wire first. Jumper must be between L1 and L3. System is factory configured for 208VAC output.

  • Page 41: For 120/208/240 Vac Outputs (Shown With One Exb)

    2.7.2 Connecting EX RT Transformer Module (Part number 86211) This module is to provide isolated 120/208/240 VAC outputs to the protected loads. Figure 2-13: View of EX RT Transformer Module connected downstream for 120/208/240 Vac outputs (shown with one EXB). BATTERY MODULE EXB 5/7/11 RT AC NORMAL...

  • Page 42: And Simplified Connection Diagram

    EX 5/7/11RT Systems 2.7.3 Connections with Separate Normal and Bypass AC sources (2 Mains) CAUTION: This connection requires isolation Transformer Module. Call MGE Technical Support for details. Figure 2-14: Normal AC and Bypass AC inputs, Output Cables Installation, and Simplified Connection Diagram. Output Transformer Module With separate Normal and Bypass AC inputs, supplied by separate sources.

  • Page 43: Accessing Terminal Blocks For Input And Output Power Cables

    2.7.4 System Connections as Frequency Converter (without Bypass AC source) Figure 2-15: Accessing Terminal Blocks for Input and Output power cables. OF F Power Module I/O Box Output 200/208/220/230/240Vac 200/208/220/230/240Vac Normal AC source 200/208/220/230/240Vac OUTPUT To Load 208VAC 86-86000-00 B00 CAUTION: 1.

  • Page 44: Rear View Of Battery Module Cable Connections

    EX 5/7/11RT Systems Connection of Battery Module EXB 1. Check that the battery circuit breaker (5) 2. Connect the battery power cable Modules. 3. Connect the battery detection cable Modules. Figure 2-16: Rear view of Battery Module cable connections. 2 — 18 is OFF (“0”) position.

  • Page 45: Rear View Of Cla Module Cable Battery And Ac Input Connections

    Connection of Optional CLA Module 1. Connect the battery power cable between the Power Module and the CLA Module. 2. Connect the DC Input of the CLA Module to high power battery cabinet. ◗ DC Input Cable cross-section (not provided): maximum 4 AWG solid or stranded wire. 3.
  • Page 46 EX 5/7/11RT Systems (This page left blank intentionally) 86-86000-00 B00 2 — 20...

  • Page 47: Operation

    Scope Operation describes EX 5/7/11RT systems characteristics of indicators and controls, modes and specifications and theory of operating the EX 5/7/11RT. The user procedures include performing software programming that will maintain smooth performance. Refer to Figure 1.6 for descriptions of circled numbers. Initial Startup NOTE Both AC and DC sources must be present for normal startup of EX 5/7/11RT...

  • Page 48: Control Panel With Scroll Up And Down Buttons

    EX 5/7/11RT Systems UPS Personalization WARNING Before changing items from Tables, 3-1, 3-2, 3-3, and 3-4, the UPS system must be turned OFF. IMPORTANT If specific settings are required, it is recommended to enter the UPS personalization mode at this stage. It is possible to enter this mode through the front panel buttons or the Solution-Pac 2 software for Windows included in the MGE UPS SYSTEMS, INC.

  • Page 49: Configuration Used To Provide Cascade Redundancy To Critical Loads

    Table 3-1: Local Settings. Display Factory setting Language English Date/time format International Date/time change (DD-MM-YYYY/HH:MM) Audible alarm Quick beeps Table 3-2: Output Features. Display Factory setting Output voltage 208 Volts AC (***) Frequency converter Disabled Output frequency Auto ranging ECO mode Disabled Hot standby Disabled...

  • Page 50: Battery Features

    Options Comments No test/daily/monthly 0 to 100% Low battery signal;1% increment From 50 to 400 Ah Requires CLA Module if using options (see section 1.5.8) Disabled If disabled, loss of MGE UPS SYSTEMS, INC. warranty. Operation 86-86000-00 B00...

  • Page 51: Information Technology It Network And Industrial Operating Modes

    Information Technology IT Network and Industrial Operating Modes Table 3-5: System Operation in IT Netowrk and Industrial Modes. Symptoms Overload, and Bypass source in tolerance. Overload, and Bypass AC source not in tolerance. Output short circuit and Bypass The load remains powered by the UPS. AC source in tolerance.

  • Page 52: Ups Personalization Through External Software

    EX 5/7/11RT Systems 3.3.1 UPS personalization through external software Insert the Solution-Pac 2 CD ROM in your CD drive. ◗ At the first Navigator Screen, select "Installation" and follow the instructions to install Solution-Pac 2 for Windows. ◗ If nothing appears, launch startup.exe ◗...

  • Page 53: Operating Modes

    Operating Modes 3.4.1 Normal (double conversion) Mode Figure 3-4: Normal (double conversion) mode. LOAD LEVEL 4kW / 5 kVA REMAINING TIME 10 minutes 86-86000-00 B00 This is the standard operating mode, set by the factory. Two possible cases. 1. If Normal AC source available: LED is ON.

  • Page 54: Eco Mode

    EX 5/7/11RT Systems 3.4.2 ECO Mode Figure 3-5: ECO mode display. 3 — 8 The main advantage of the ECO mode is that it reduces the consumption of electrical power by not running in the online mode. When this mode is selected, the system works as an offline UPS system, powered by Bypass source if Bypass source is inside user’s defined range.

  • Page 55: Transfer, Threshold And End Of Backup Time

    Operation on Battery Power Figure 3-6: Transfer, Threshold and End of backup time. REMAINING TIME 10 minutes REMAINING TIME 2 minutes 86-86000-00 B00 3.5.1 Transfer to Battery Power The load continues to be protected by the UPS when the Normal AC source is not available. Power is supplied by the battery.

  • Page 56: Return Of Normal Ac Source

    EX 5/7/11RT Systems Return of Normal AC source After an outage, the UPS restarts automatically when AC power is restored (unless this function has been disabled via UPS personalization). Shutdown Figure 3-7: Shutdown display, circuit breaker, and AC source switch. 3 —...

  • Page 57: Maintenance

    Scope Maintenance includes a troubleshooting guide of symptoms and possible solutions, hot swapping the Power Module and Battery Module, and testing scenarios. Troubleshooting ◗ If any of LEDs ◗ Use "scroll up" or "scroll down" function button to reset the audible alarm. Table 4-1: Troubleshooting not requiring MGE after-sales support.

  • Page 58: Troubleshooting Requiring Mge After-Sales Support

    EX 5/7/11RT Systems Table 4-2: Troubleshooting requiring MGE after-sales support. Symptoms are on, Bypass AC Source is present business and audible alarm is on. the LCD display shows: xxx FAULT is on, and audible alarm is on, the LCD display shows BATTERY FAULT is on, the LCD display shows:...

  • Page 59: Hot Swapping The Power Module

    Hot Swapping the Power Module This operation can be performed without interrupting the load. Figure 4-1: Disconnecting the Power Module. XXX FAULT 1CXXXXXXX Set ting Car d data 8FF 855 660 74 =00 E0D Res et nloa 32 Dow φ 86-86000-00 B00 1.

  • Page 60: Re-Connecting The Power Module

    EX 5/7/11RT Systems Re-connecting the Power Module This operation can be performed without interrupting the load. Figure 4-2: Reconnect the Power Module. LOAD LEVEL 4 kW/ 5 kVA 4 — 4 1. Secure the Input/Output box using the three screws. 2.

  • Page 61: Rear View Of The Battery Module

    Hot Swapping the Battery Module During the replacement of the Battery Module, it is imperative to use the same type and number of element as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. In case of doubt, don’t hesitate to contact our Customer Care Center for more information, or refer to our web site at www.mgeups.com.
  • Page 62 EX 5/7/11RT Systems (This page left blank intentionally) 86-86000-00 B00 4 — 6...

  • Page 63: Power Supplied As A Function Of Input Voltage (Left And Permissible Ups Overloads As A Function Of Time (Right)

    Electrical Specifications Electrical and Mechanical specifications for the EX 5/7/11RT. System Input/Output Power Ratings Table 5-1: EX 5/7/11 RT Voltages and Frequency Characteristics. Source Normal AC Source Bypass AC Source Load Output (*): depends on output voltage setting, can be modified by software. (**): set to +/- 4% by default, (1, 2, 4, 8% are possible values), can be modified by software.

  • Page 64: System Backup Characteristics

    EX 5/7/11RT Systems System Backup Characteristics Table 5-2: Backup Time (in minutes). 11 kVA with 9Ah battery modules: Standard Std + 1 EXB Std + 2 EXB Std + 3 EXB Std + 4 EXB Std + 5 EXB 7 kVA with 7Ah battery modules: Standard Std + 1 EXB Std + 2 EXB...
  • Page 65 Table 5-3: Battery Recharge time to recover 90% of the rated backup time after discharge at full load. Configuration for 2 hours backup time EX 5RT 7 hours EX 7RT 5 hours EX 11RT 7 hours Table 5-4: Efficiency online (RL load) and batteries fully charged. kVA / kW 5kVA / 4kWatts...

  • Page 66: Heat Rejection

    EX 5/7/11RT Systems Table 5-7: Efficiency on ECO mode (all kinds of load) and batteries fully charged. kVA / kW 5kVA / 4kWatts 7kVA / 4.9kWatts 11kVA / 8kWatts Heat Rejection Table 5-8: Full load heat rejection in BTU’s/hr. System Operation Mode On-line 5kVA...

  • Page 67: Mge Warranty & Proprietary Rights For Single Phase Products

    MGE UPS SYSTEMS, INC. and shall not be part of any warranty There are no warranties which extend beyond the description on the face hereof. In no event shall MGE UPS SYSTEMS, INC. be responsible for consequential damages or for any other damages except as expressly stated herein.

  • Page 68: Warranty And Product Registration

    Warranty and Product Registration Thank you for choosing MGE UPS SYSTEMS, INC. for your power protection, distribution, and quality requirements. We are pleased to have you join our increasing family of users. In order to maximize the value you receive from this product, and to ensure that you are kept informed of product or software updates, we recommend that you take a few minutes to register your new purchase.
  • Page 69 Customer Care Center: Customer FAQ or International calls: Commitment: MGE UPS SYSTEMS, INC. is committed to providing easy to access factory trained experts that will provide responses to any questions that you might have. Scheduling Field Service Engineer Support Scheduling of the MGE Field Service Engineers typically should be done 7 to 10 days before they are required on-site.
  • Page 70 EX 5/7/11RT Systems (This page left blank intentionally) 86-86000-00 B00 W—4...
  • Page 71 Term used Definition/Meaning And/or. Plus or Minus. ≤ Equal to or less than. Number. °C Degree Celsius. °F Degree Fahrenheit. Ø Phase angle. Ω Ohm; unit of resistance. ® Trade Mark. Second. AC or ac Alternating current, also implies root-mean-square (rms). Ambient Temp.
  • Page 72 EX 5/7/11RT Systems dBrnC Decibel above reference noise. DC or dc Direct current, or voltage. Earth ground A ground circuit that has contact with the earth. Electrician Refers to an installation electrician qualified to install heavy-duty electrical components in accordance with local codes and regulations. Not necessarily qualified to maintain or repair electrical or electronic equipment.
  • Page 73 Part number. Pulse Width Modulation. Load consists of resistor, capacitor and diode. A computer with switched mode power supply is considered a RCD load. Load consists of resistor, and inductor. A fan or a drill is considered a RL load.
  • Page 74 EX 5/7/11RT Systems (This page left blank intentionally) 86-86000-00 B00 G — 4...

  • Page 75: Scenic Avenue Costa Mesa, Ca

    A free copy of this document may be downloaded from the proprietary MGE Rep Web site. Please contact your MGE UPS SYSTEMS, INC. Representative for assistance. NAME...

  • Page 76: Mge Ups Systems

    . m g e u p s . c o m Contact MGE United States MGE UPS SYSTEMS 1660 Scenic Ave. Costa Mesa, CA 92626 Tel: (714) 557-1636 (800) 523-0142 Fax: (714) 557-9788 email: info@mgeups.com www: mgeups.com...
