4.4

Re-connecting the power module

This operation can be performed without interrupting the load.
Figure 4-2: Reconnect the power module.
86-86000-00 A01
15
17
LOAD LEVEL
4 kW/ 5 kVA
OFF ON
22
1. Secure the Input/Output junction box using the
three screws.
2. Reconnect the cables
power module.
3. Switch the battery circuit breaker(s)
ON position.
4. Check if Normal AC source circuit breaker
8
is on the ON position.
5. Check that the LED
6. Turn the manual bypass switch from the
BYPASS to the NORMAL position.
7. Follow initial start up sequence (see section
3.1) in order to personalize the UPS.
8. Push the ON button
seconds.
The green LED
equipment is now protected by the UPS.
Maintenance
Installation and User Manual
40 42
and
14
17
is on.
22
for more than 3
15
is on, and the connected
to the
to the
4 — 5
