HP IBASIC (EXT_ARM)
C and QuickBASIC
Programs
Chapter 5
1
!RE-SAVE"EXT_ARM"
2
!This program arms the AFG with an external signal applied to the
3
!AFG's "Aux In" port. When armed, the AFG outputs 100 cycles
4
!of a 10 kHz, 1 Vpp square wave.
5
!
10
!Assign I/O path between IBASIC and the E1340A.
20
ASSIGN @Afg TO 80910
30
COM @Afg
40
!
50
!Set up error checking
60
ON INTR 8 CALL Errmsg
70
ENABLE INTR 8;2
80
OUTPUT @Afg;"*CLS"
90
OUTPUT @Afg;"*SRE 32"
100
OUTPUT @Afg;"*ESE 60"
110
!
120
!Call the subprogram which resets the AFG.
130
CALL Rst
140
!
150
!Set AFG parameters
160
OUTPUT @Afg;"SOUR:FREQ:MODE FIX;";!frequency mode
170
OUTPUT @Afg;":SOUR:FREQ:FIX 1E3;";!frequency
180
OUTPUT @Afg;":SOUR:FUNC:SHAP SQU;"; !function
190
OUTPUT @Afg;":SOUR:VOLT:LEV:IMM:AMPL 1VPP;"; !amplitude
200
OUTPUT @Afg;":ARM:STAR:LAY2:SOUR EXT;"; !arm source
210
OUTPUT @Afg;":ARM:STAR:LAY2:COUN INF;"; !arm count
220
OUTPUT @Afg;":ARM:STAR:LAY1:COUN 1E3" !cycle count
230
OUTPUT @Afg;"INIT:IMM"
240
!
250
WAIT .1
260
OFF INTR 8
270
END
280
!
290
SUB Rst
360
SUB Errmsg
The C program EXT_ARM.C is in directory " CPROG" , and the
QuickBASIC program EXT_ARM.BAS is in directory " QBPROG" on the
example program disk HP P/N E1340-10036.
HP E1340A Arming and Marker Outputs
!wait-for-arm state
!allow interrupt to be serviced
98
