C and QuickBASIC
Program Versions
77
Generating Arbitrary Waveforms with the HP E1340A
120
!Call the subprogram which resets the AFG.
130
CALL Rst
140
!
150
!Set AFG parameters
160
OUTPUT @Afg;"SOUR:FREQ:FIX 1E3;";!frequency
170
OUTPUT @Afg;":SOUR:FUNC:SHAP USER;";!function
180
OUTPUT @Afg;":SOUR:VOLT:LEV:IMM:AMPL 1.1V" !scale
190
!
200
!Call subprogram which defines waveform segment.
210
CALL Damped_sine
220
!
230
!Select output sequence and initiate waveform
240
OUTPUT @Afg;"SOUR:FUNC:USER A"
250
OUTPUT @Afg;"INIT:IMM"
260
!
270
WAIT .1
280
OFF INTR 8
290
END
300
!
310
SUB Damped_sine
320 Damped_sine: !Subprogram which defines a damped sine wave
330
COM @Afg,Waveform(*)
340
A=4/4096
350
W=(2*PI)/50
360
FOR T=1 TO 4096
370
Waveform(T)=EXP(-A*T)*SIN(W*T)
380
NEXT T
390
!
400
OUTPUT @Afg;"SOUR:LIST:SEGM:SEL A"!select segment name
410
OUTPUT @Afg;"SOUR:LIST:SEGM:VOLT";Waveform(*)!load
420
SUBEND
430
!
440
SUB Rst
510
SUB Errmsg
The C example program, SIN_D.C, is in directory " CPROG" and the
QuickBASIC example program, SIN_D.BAS, is in directory " QBPROG"
on the C and QuickBASIC example disk (part number E1340-10036).
amplitude
!wait-for-arm state
!allow interrupt to be serviced
waveform points
Chapter 3
